In Stock MTL4641 Repeater Power Supply 4/20mA, HART, 2- or 3-wire transmitters

News August 25, 2023

In Stock MTL4641 Repeater Power Supply 4/20mA, HART, 2- or 3-wire transmitters


In Stock MTL4641 Repeater Power Supply 4/20mA, HART, 2- or 3-wire transmitters

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761


Number of channels

One

Output

Signal range: 4 to 20mA

Under/over-range: 0 to 24mA

Load resistance (MTL4641)

@ 24mA: 0 to 375Ω

@ 20mA: 0 to 465Ω

Load (MTL4641S)

Current sink: 600Ω max.

Maximum voltage source: 24V dc

Circuit output resistance: > 1MΩ

Circuit ripple

< 50µA peak-to-peak

Input

Signal range: 0 to 24mA (including over-range)

Transmitter voltage: 20V at 20mA (MTL4641)

16.5V at 20mA (MTL4641S)

Transfer accuracy at 20°C

Better than 20µA 4-20mA (Terminals 1 & 2)

Better than 30µA 4-20mA (Terminals 1 & 3)

Temperature drift

< 0.8µA/°C

Response time

Settles to within 10% of final value within 50µs

Communications supported

HART (terminals 1 & 2 only)

LED indicator

Green: power indication

Maximum current consumption (with 20mA signal)

53mA at 24V

Power dissipation within unit (with 20mA signal)

MTL4641 0.8W @ 24V dc

MTL4641S 1.0W @ 24V dc
