Belden 3076F 003(ORG)1000FT305 MTR Multi-Pair Cable Fieldbus, 1 Pair 18AWG (7x26) Tinned Copper, PP Insulation

News August 25, 2023

Belden 3076F 003(ORG)1000FT305 MTR  Multi-Pair Cable Fieldbus, 1 Pair 18AWG (7x26) Tinned Copper, PP Insulation

3076F 003(ORG)1000FT305 MTR (2).JPG

3076F 003(ORG)1000FT305 MTR (1).JPG

Belden 3076F 003(ORG)1000FT305 MTR  Multi-Pair Cable Fieldbus, 1 Pair 18AWG (7x26) Tinned Copper, PP Insulation

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761


Mechanical Characteristics

TEMPERATURE

UL Temperature Operating

105°C -40°C to +105°C

BEND RADIUS

Stationary Min. Installation Min.

6.5 in (170 mm) 2.80 in (71.1 mm)

Max. Pull Tension 60 lbs (27 kg)

Bulk Cable Weight 44 lbs/1000ft

Standards and Compliance

Environmental Suitability Indoor, Outdoor, Sunlight Resistance, Oil Resistance, Oil Resistance, Burial

Flammability / Reaction to Fire UL 1685 UL Loading, FT4, IEEE 1202, IEC 60332-1-2

CPR Compliance CPR Euroclass: Eca; CPR UKCA Class: Eca

NEC / UL Compliance Article 725, Article 727, Article 800, CMG, ITC, PLTC, TC

CEC / C(UL) Compliance CMG

ISO/IEC Compliance IEC 61158-2

European Directive Compliance EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)

UK Regulation Compliance UKCA Mark

Other Standard Compliance(s) ISA/SP-50 Type A

Product Notes

Notes Fieldbus: Orange jacket. Profibus PA: Intrinsically Safe Blue jacket. Jacket diameter tolerance: +/- .010
