Festo VMPA1-M1H-KU-PI 553110 Air Solenoid Valve

Festo VMPA1-M1H-KU-PI 553110 Air Solenoid Valve

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

• Valve function2x3/2, closed, monostable

• Actuation typeElectrical

• Valve size10 mm

• Standard nominal flow rate160 l/min

• Operating voltage24V DC

• Operating pressure-0.09 MPa ... 1 MPa

• Operating pressure-0.9 bar ... 10 bar

• Structural designPoppet valve with return spring

• Reset methodMechanical spring

• Certificationc UL us - Recognized (OL)

• Certificate issuing authorityUL MH19482

• Degree of protectionIP65 In mounted state as per IEC 60529

• Sealing principleSoft

• Mounting positionAny

• Manual overrideDetenting Non-detenting

• Type of controlPilot-controlled

• Flow directionReversible

• Symbol00992874

• LapUnderlap

• Signal status displayyes

• Pilot pressure MPa0.4 MPa ... 0.8 MPa

• Pilot pressure4 bar ... 8 bar

• Suitability for vacuumyes

• Standard nominal flow rate with QS-6160 l/min

• Switching time off10 ms

• On switching time8 ms

• Max. positive test pulse with 0 signal400 µs

• Max. negative test pulse on 1 signal200 µs

• Permissible voltage fluctuations+/- 25 %

• Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]

• Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)

• Vibration resistanceTransport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6

• Shock resistanceShock test with severity level 2 as per FN 942017-5 and EN 60068-2-27

• Corrosion resistance class (CRC)3 - High corrosion stress

• LABS (PWIS) conformityVDMA24364-B1/B2-L

• Storage temperature-20 °C ... 40 °C

• Temperature of medium-5 °C ... 50 °C

• Relative air humidityMax. 90 % at 40 °C

• Ambient temperature-5 °C ... 50 °C

• Max. tightening torque for valve mounting0.25 Nm

• Product weight42 g

• Type of mountingWith through-hole

• Note on materialsRoHS-compliant

• Seals materialNBR

• Housing materialPPA-reinforced
