Pepperl + Fuchs FN-LB-I Surge Protection Barrier

News August 04, 2023

Pepperl + Fuchs FN-LB-I Surge Protection Barrier


Pepperl + Fuchs FN-LB-I Surge Protection Barrier

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761


General specifications

Number of protected signal lines 1

Functional safety related parameters

Safety Integrity Level (SIL) SIL 3

Supply

Rated voltage ≤ 48 V

Rated current ≤ 250 mA

Leakage current ≤ 5 µA

On-state voltage ≤ 85 V

Ground insulation ≥ 500 V breakdown voltage

Electrical specifications

Total discharge current (8/20 µs) 20 kA

Conformity

Degree of protection IEC 60529:2001

Ambient conditions

Ambient temperature -30 ... 60 °C (-22 ... 140 °F) For usage in hazardous area observe EC-type examination certificate.

Mechanical specifications

Housing material Stainless steel 1.4401 (AISI 316)

surface all over polished

Degree of protection IP67

Cable

Length 0.3 m

Mass approx. 200 g

Dimensions AF22 x 77 mm (0.9 x 3 inch)

Mounting NPT1/2 thread

Data for application in connection with hazardous areas

EU-type examination certificate PTB 00 ATEX 2175

Marking Ex-Hexagon II 2G EEx ia IIC T6

Voltage 50 V

Maximum leakage current 10 kA line to ground (common), 5 kA line to line (differential) in accordance to IEC 60-2

Nominal response time

Symmetrical 1 ns

Asymmetric 100 ns

Bandwidth ≥ 40 kHz

Directive conformity

Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012
