In Stock Pepperl+Fuchs NCN4-12GM35-N0-V1 Inductive Sensor

In Stock Pepperl+Fuchs NCN4-12GM35-N0-V1 Inductive Sensor

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

General specifications

Switching function Normally closed (NC)

Output type NAMUR

Rated operating distance 4 mm

Installation non-flush

Assured operating distance 0 ... 3.24 mm

Actual operating distance 3.6 ... 4.4 mm typ.

Reduction factor rAl 0.37

Reduction factor rCu 0.36

Reduction factor r304 0.74

Output type 2-wire

Nominal ratings

Nominal voltage 8.2 V (Ri approx. 1 kΩ)

Switching frequency 0 ... 800 Hz

Hysteresis 1 ... 10 typ. 5 %

Reverse polarity protection reverse polarity protected

Short-circuit protection yes

Current consumption

Measuring plate not detected min. 3 mA

Measuring plate detected ≤ 1 mA

Switching state indicator Multihole-LED, yellow

Functional safety related parameters

Safety Integrity Level (SIL) SIL 2

MTTFd 2520 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 0 %

Compliance with standards and directives

Standard conformity

NAMUR EN 60947-5-6:2000

IEC 60947-5-6:1999

Electromagnetic compatibility NE 21:2007

Standards EN 60947-5-2:2007

EN 60947-5-2/A1:2012

IEC 60947-5-2:2007

IEC 60947-5-2 AMD 1:2012

In Stock Pepperl+Fuchs NCN4-12GM35-N0-V1 Inductive Sensor

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Approvals and certificates

IECEx approval

Equipment protection level Ga IECEx PTB 11.0037X

Equipment protection level Gb IECEx PTB 11.0037X

Equipment protection level Da IECEx PTB 11.0037X

Equipment protection level Mb IECEx PTB 11.0037X

ATEX approval

Equipment protection level Ga PTB 00 ATEX 2048 X

Equipment protection level Gb PTB 00 ATEX 2048 X

Equipment protection level Da PTB 00 ATEX 2048 X

UL approval

Ordinary Location E87056

Hazardous Location E501628

Control drawing 116-0452

CCC approval

Hazardous Location 2020322315002255

NEPSI approval

NEPSI certificate GYJ16.1393X

TIIS approval on request

ANZEx 18.3018X

KCC approval

Hazardous Location 09-AV4BO-0225

Marine approval DNVGL TAA00001A5

RINA ELE096617XG

Ambient conditions

Ambient temperature -25 ... 100 °C (-13 ... 212 °F)

Storage temperature -40 ... 100 °C (-40 ... 212 °F)

Mechanical specifications

Connection type Connector plug

Housing material Stainless steel 1.4305 / AISI 303

Sensing face PBT

Degree of protection IP66 / IP67

Connector

Threading M12 x 1

Number of pins 4
