Festo SIM-M8-3GD-2,5-PU 159420 Connecting Cable

Festo SIM-M8-3GD-2,5-PU 159420 Connecting Cable

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

• Conforms to standardEN 61076-2-104 EN 61984

• Electrical connection3-pin/3-wire Straight socket/open end M8x1 / -

• Symbol00991871

• DC operating voltage range0 V ... 60 V

• Operating voltage range AC0 V ... 60 V

• Current rating at 40° C4 A

• Surge resistance1.5 kV

• Cable length2.5 m

• Cable characteristicStandard

• Connector cable test conditionsFlexural strength: as per Festo standard Test conditions on request Energy chain > 5 million cycles, bending radius 75 mm

• Cable diameter3.8 mm

• Cable design3 x 0.25 mm²

• Nominal conductor cross section0.25 mm²

• Wire insulation color codeBlue Brown Black

• Degree of protectionIP65 IP68

• Ambient temperature-25 °C ... 80 °C

• Ambient temperature with flexible cable installation-5 °C ... 80 °C

• CE marking (see declaration of conformity)As per EU low voltage directive As per EU RoHS directive

• UKCA marking (see declaration of conformity)To UK instructions for electrical equipment To UK RoHS instructions

• LABS (PWIS) conformityVDMA24364-B2-L

• Note on materialsRoHS-compliant Halogen-free Free of phosphoric acid ester

• Contamination level3

• Corrosion resistance class (CRC)2 - Moderate corrosion stress

• Material of cable sheathTPE-U(PU)

• Color cable sheathGray

• Housing materialTPE-U(PU)

• Housing colourBlack

• Material of union nutBrass, nickel-plated

• Seals materialNBR

• Material of pin contactsBrass, gold-plated

• Insulating sheath materialPP
