Schneider Electric XCKMR54D1 Limit switch, Limit switches XC Standard, XCKMR, stay put crossed rods lever 6 mm, 2x(2 NC), slow, Pg13

Schneider Electric XCKMR54D1 Limit switch, Limit switches XC Standard, XCKMR, stay put crossed rods lever 6 mm, 2x(2 NC), slow, Pg13

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of product OsiSense XC

Series name Special format

Product or component type Limit switch

Product specific application For hoisting and mechanical handling applications

device short name XCKMR

body type Fixed

Head type Rotary head

Material Metal

Body material Zamak

Head material Zamak

Fixing mode By the body

Movement of operating head Rotary

Type of operator Stay put crossed rods lever metal square rod 6 mm, L = 200 mm

Type of approach Lateral approach, 2 directions

Cable entry 3 entries tapped for Pg 13.5 cable gland, cable outer diameter: 9…12 mm

Number of poles 4

Contacts type and composition 2 x (2 NC)

Contact operation Slow-break, staggered

Complementary

Switch actuation By any moving part

Electrical connection Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²

Contacts insulation form Zb

Number of steps 5 electrical positions

Contact block per direction [control circuit] 1 per direction

Positive opening With

Positive opening minimum torque 0.75 N.m

Minimum torque for tripping 0.5 N.m

Minimum actuation speed 6 m/min

Maximum actuation speed 1.5 m/s actuation point on the rod between 65 and 95 mm

Maximum displacement angle -180 °

180 °

Contact code designation A300, AC-15 (Ue = 240 V), Ie = 3 A, Ithe = 10 A conforming to EN/IEC 60947-5-1 appendix A

Q150, DC-13 (Ue = 125 V), Ie = 0.55 A conforming to EN/IEC 60947-5-1 appendix A

[Ui] rated insulation voltage 300 V conforming to UL 508

300 V conforming to CSA C22.2 No 14

500 V (pollution degree 3) conforming to EN/IEC 60947-1

Maximum resistance across terminals 25 MOhm conforming to IEC 60255-7 category 3

[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60664

6 kV conforming to EN/IEC 60947-1

Short-circuit protection 10 A cartridge fuse, type gG

Mechanical durability 2000000 cycles

Width 200 mm

Height 118 mm

Depth 59 mm

Product weight 0.55 kg

Terminals description ISO n°1 (11-12)NC

(21-22)NC

Environment

Shock resistance 50 gn conforming to EN/IEC 60068-2-27

Vibration resistance 25 gn (f= 10…500 Hz) conforming to EN/IEC 60068-2-6

IP degree of protection IP66 conforming to EN/IEC 60529

IK degree of protection IK07 conforming to EN 50102

Electrical shock protection class Class I conforming to IEC 60536

Ambient air temperature for operation -40…70 °C

Ambient air temperature for storage -40…85 °C

Protective treatment TC

Product certifications UL

CCC

CSA

CE

Standards EN/IEC 60947-5-1

UL 508

CSA C22.2 No 14

Packing Units

Unit Type of Package 1 PCE

Number of Units in Package 1 1

Package 1 Height 13.0 cm

Package 1 Width 11.0 cm

Package 1 Length 23.0 cm

Package 1 Weight 725.0 g

Unit Type of Package 2 S02

Number of Units in Package 2 6

Package 2 Height 15.0 cm

Package 2 Width 30.0 cm

Package 2 Length 40.0 cm

Package 2 Weight 4.955 kg

Unit Type of Package 3 P06

Number of Units in Package 3 96

Package 3 Height 77.0 cm

Package 3 Width 80.0 cm

Package 3 Length 60.0 cm

Package 3 Weight 85.38 kg
