Festo PEV-1/4-B-OD 175250 Pressure Switch

Festo PEV-1/4-B-OD 175250 Pressure Switch

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

•Conforms to standardEN 60947-5-1

•Symbol00991471

•CertificationCCC

•CE marking (see declaration of conformity)As per EU low voltage directive

•UKCA marking (see declaration of conformity)To UK instructions for electrical equipment

•Explosion prevention and protectionObserve the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)

•Note on materialsRoHS-compliant

•Measured variableRelative pressure

•Method of measurementPneumatic/electric pressure transducer

•Operating pressure0.1 MPa ... 1.2 MPa

•Operating pressure1 bar ... 12 bar

•Operating mediumCompressed air as per ISO 8573-1:2010 [7:-:-] Water

•Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)

•Temperature of medium-20 °C ... 80 °C

•Ambient temperature-20 °C ... 80 °C

•Switching element functionChangeover switch

•Max. switching frequency3 Hz

•Max. switching output voltage AC250 V

•Max. switching output voltage DC125 V

•Max. output current5000 mA

•Minimum load current1 mA at 24 V 10 mA at 10 V 100 mA at 5V

•Utilization category for inductive loadAC-14 DC-13

•Utilization category for ohmic loadAC-12 DC-12

•Electrical connectionForm A Plug as per DIN 43650 Rectangular design

•Type of mountingWith through-hole

•Mounting positionAny

•Pneumatic connectionG1/4

•Product weight194 g

•Housing materialDie-cast aluminum

•Switching contact materialSilver

•Switching status indicationLED yellow

•Setting range threshold value1 bar ... 12 bar

•Degree of protectionIP65

•Corrosion resistance class (CRC)2 - Moderate corrosion stress

•LABS (PWIS) conformityVDMA24364-B1/B2-L

Festo PEV-1/4-B-OD 175250 Pressure Switch

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Similar model numbers:

PEV-1/4-B

PEV-1/4-B-OD

PEV-1/4-B-M12
