Festo DSNU-20-25-P-A 19208 ISO Cylinder

News June 30, 2023

Festo DSNU-20-25-P-A 19208 ISO Cylinder


Festo DSNU-20-25-P-A 19208 ISO Cylinder

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


• Stroke25 mm

• Piston diameter20 mm

• Piston rod threadM8

• CushioningElastic cushioning rings/pads at both ends

• Mounting positionAny

• Conforms to standardCETOP RP 52 P ISO 6432

• Piston rod endExternal thread

• Structural designPiston Piston rod Cylinder barrel

• Position sensingFor proximity sensor

• Symbol00991217

• VariantsPiston rod at one end

• Operating pressure0.1 MPa ... 1 MPa

• Operating pressure1 bar ... 10 bar

• Mode of operationDouble-acting

• Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]

• Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)

• Corrosion resistance class (CRC)2 - Moderate corrosion stress

• LABS (PWIS) conformityVDMA24364-B1/B2-L

• Cleanroom classClass 6 according to ISO 14644-1

• Ambient temperature-20 °C ... 80 °C

• Impact energy in the end positions0.2 J

• Theoretical force at 6 bar, retracting158.3 N

• Theoretical force at 6 bar, advancing188.5 N

• Moving mass at 0 mm stroke44 g

• Additional moving mass per 10 mm stroke4 g

• Basic weight with 0 mm stroke186.8 g

• Additional weight per 10 mm stroke7.2 g

• Type of mountingWith accessories

• Pneumatic connectionG1/8

• Note on materialsRoHS-compliant

• Cover materialWrought aluminum alloy Plain anodized

• Seals materialNBR TPE-U(PU)

• Piston rod materialHigh-alloy stainless steel

• Material of cylinder barrelHigh-alloy stainless steel


Festo DSNU-20-25-P-A 19208 ISO Cylinder

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Similar model numbers:

DSNU-20-50-P-A

DSNU-20-50-PPS-A

DSNU-20-50-PPV-A

DSNU-20-20-P-A

DSNU-20-20-PPS-A

DSNU-20-20-PPV-A

DSNU-20-25-P-A

DSNU-20-25-PPS-A

DSNU-20-25-PPS-A

DSNU-20-200-P-A

DSNU-20-200-PPS-A

DSNU-20-200-PPV-A

DSNU-20-250-P-A
