Festo DSBC-63-80-PPVA-N3 1383581 ISO Cylinder

Festo DSBC-63-80-PPVA-N3 1383581 ISO Cylinder

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

•Stroke80 mm

•Piston diameter63 mm

•Piston rod threadM16x1.5

•CushioningPneumatic cushioning, adjustable at both ends

•Mounting positionAny

•Conforms to standardISO 15552

•Piston rod endExternal thread

•Structural designPiston Piston rod Profile barrel

•Position sensingFor proximity sensor

•Symbol00991235

•VariantsPiston rod at one end

•Operating pressure0.04 MPa ... 1.2 MPa

•Operating pressure0.4 bar ... 12 bar

•Mode of operationDouble-acting

•Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]

•Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)

•Corrosion resistance class (CRC)2 - Moderate corrosion stress

•LABS (PWIS) conformityVDMA24364-B1/B2-L

•Ambient temperature-20 °C ... 80 °C

•Impact energy in the end positions1.3 J

•Cushioning length22 mm

•Theoretical force at 6 bar, retracting1682 N

•Theoretical force at 6 bar, advancing1870 N

•Moving mass at 0 mm stroke430 g

•Additional moving mass per 10 mm stroke25 g

•Basic weight with 0 mm stroke1740 g

•Additional weight per 10 mm stroke62 g

•Type of mountingOptionally: With internal thread With accessories

•Pneumatic connectionG3/8

•Note on materialsRoHS-compliant

•Cover materialDie-cast aluminum, coated

•Piston seal materialTPE-U(PU)

•Material of pistonWrought aluminum alloy

•Piston rod materialHigh-alloy steel

•Piston rod wiper materialTPE-U(PU)

•Buffer seal materialTPE-U(PU)

•Cushion piston materialPOM

•Material of cylinder barrelWrought aluminum alloy, smooth-anodized

•Nut materialSteel, galvanized

•Material of bearingPOM

•Flange screws materialSteel, galvanized

Festo DSBC-63-80-PPVA-N3 1383581 ISO Cylinder

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Similar model numbers:

DSBC-63-80-PPSA-N3

DSBC-63-80-PPVA-N3

DSBC-63-80-D3-PPSA-N3

DSBC-63-80-D3-PPVA-N3
