In Stock Hydac 907288, EDS 346-3-100-000 Electronic Pressure Switch

In Stock Hydac 907288, EDS 346-3-100-000 Electronic Pressure Switch

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761

The EDS 300 is a compact, electronic pressure switch with integrated digital display. The integrated pressure sensor is based on a measurement cell with thin-fi lm strain gauge on a stainless steel membrane. Four different output models are available: with one switch point or with two switch points and both models can also have an additional Analog output signal 4 to 20 mA. The switch points and the associated hysteresis can be adjusted using the key pad. For optimum adaptation to a particular application, the instrument has many additional adjustment parameters, e.g. switching delay times, N/O / N/C function of the outputs.

Features

Switching mode of the switching outputs adjustable (switch point function or window function)

Switching direction of the switching outputs adjustable (N/C or N/O function) Switch-on and switch-off delay adjustable from 0.0 to 75.0 seconds

Choice of display (actual pressure, peak value, switch point 1, switch point 2, display off)

Optional Analog output signal 4 to 20 mA

Subsequent correction of zero point in the range ± 3 % FS possible

Tech Specifications

Item_Name EDS 3XX Pressure Switch

Seal_Material Fluorocarbon Elastomer (FKM)

Output_Signal 1 Switching Output and 1 Analog Output Only in Conjunction with Electrical Connection Type "4" or "6"

Interface 3-Digit, LED, 7 Segment, Red, Height of Digits 9.2 mm

Type Standard Pressure Switch

Switching_Function Adjustable N/O or N/C

Switching_Current_A 1.2 A

Switch_Type 1 PNP Transistor Switching Output & 1 Analog Output

Pressure_Max__bar 200 bar

Operating_Temperature_Max___C -25 to 80 ºC

Industry_Standards_Certifications EN 61000-6-1/2/3/4

Electrical_Connection Male M12x1, 4 Pole

Only Possible on Output Models "1", "2" and "3"

(Mating Connector Not Supplied)

Degree_of_Protection IP 65

Connection_Type ISO 1179-2

Connection_Size G1/4 A

Burst_Pressure_bar 500 bar
