Festo DPDM-10-10-PA 4831869 Compact air cylinder

June 08, 2023

Festo DPDM-10-10-PA 4831869 Compact air cylinder

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761

•Stroke10 mm

•Piston diameter10 mm

•CushioningElastic cushioning rings/pads at both ends

•Mounting positionAny

•Mode of operationDouble-acting

•Structural designPiston Piston rod Profile barrel

•Position sensingFor proximity sensor

•Symbol00991217

•VariantsPiston rod at one end

•Operating pressure0.15 MPa ... 0.8 MPa

•Operating pressure1.5 bar ... 8 bar

•Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]

•Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)

•Corrosion resistance class (CRC)1 - Low corrosion stress

•LABS (PWIS) conformityVDMA24364-B2-L

•Cleanroom classClass 6 according to ISO 14644-1

•Ambient temperature-10 °C ... 80 °C

•Theoretical force at 6 bar47 N

•Theoretical force at 6 bar, retracting40 N

•Theoretical force at 6 bar, advancing47 N

•Moving mass at 0 mm stroke6.3 g

•Additional moving mass per 10 mm stroke1 g

•Basic weight with 0 mm stroke30 g

•Additional weight per 10 mm stroke7.5 g

•Type of mountingOptionally: With through-hole With internal thread

•Pneumatic connectionM5

•Note on materialsRoHS-compliant

•Cover materialWrought aluminum alloy

•Seals materialNBR TPE-U(PU)

•Housing materialWrought aluminum alloy, anodized

•Piston rod materialHigh-alloy stainless steel

Festo DPDM-10-10-PA 4831869 Compact air cylinder

jeff@hkxytech.com jeff@whxyauto.com +86-15072331761

Similar model numbers:

DPDM-10-10-P-PA

DPDM-10-10-S-PA

DPDM-10-10-PA
