In Stock Pepperl+Fuchs KFD0-SD2-Ex2.1045 Solenoid Driver

In Stock Pepperl+Fuchs KFD0-SD2-Ex2.1045 Solenoid Driver

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

General specifications

Signal typeDigital Output

Functional safety related parameters

Safety Integrity Level (SIL)SIL 3

Supply

Rated voltageloop powered

Power dissipation< 1.05 W (≤ 30 V) per channel

Input

Connection sidecontrol side

Connectionterminals 7, 8; 8, 9

Rated voltage20 ... 35 V DC

Current72 mA at 20 V input voltage, load = 220 Ω

50 mA at 35 V input voltage, load = 220 Ω

Inrush current≤ 200 mA after 100 µs

Output

Connection sidefield side

Connectionterminals 1+, 2-; 4+, 5-

Internal resistormax. 282 Ω

Current≤ 45 mA

Voltage≥ 10 V

Open loop voltagemin. 22.7 V

Output rated operating current45 mA

Output signalThese values are valid for the rated operating voltage 20 ... 35 V DC.

Energized/De-energized delaysingle operation: typ. 1.7 ms/50 µs; periodical: typ. 5 µs/50 µs

Indicators/settings

Display elementsLEDs

Labelingspace for labeling at the front

Directive conformity

Electromagnetic compatibility

Directive 2014/30/EUEN 61326-1:2013 (industrial locations)

Conformity

Electromagnetic compatibilityNE 21:2006

Degree of protectionIEC 60529:2001

Protection against electrical shockUL 61010-1:2004

Ambient conditions

Ambient temperature-20 ... 60 °C (-4 ... 140 °F)

Mechanical specifications

Degree of protectionIP20

Connectionscrew terminals

Massapprox. 100 g

Dimensions20 x 107 x 115 mm (0.8 x 4.2 x 4.5 inch) (W x H x D) , housing type B1

Mountingon 35 mm DIN mounting rail acc. to EN 60715:2001
