In Stock Wago 750-461 2-channel analog input for Pt100/RTD resistance sensors

News May 26, 2023

In Stock Wago 750-461 2-channel analog input for Pt100/RTD resistance sensors


In Stock Wago 750-461 2-channel analog input for Pt100/RTD resistance sensors

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Number of analog inputs 2

Total number of channels (module) 2

Signal type Resistance measurement

Resistance measurement

Sensor connection 2 x (2-wire, 3-wire)

Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)

Resolution (over entire range) 0.1 °C

Conversion time (typ.) 320ms

Measurement error (reference temperature) 25°C

Measurement error, deviation (max.) from the upper-range value 0.2%

Temperature error (max.) of the upper-range value 0.01%/K

Measuring current (typ.) 0.5 mA

Response time (max.) 4s

Sensor types Pt100

Temperature range −200 … +850 °C

Supply voltage (system) 5 VDC; via data contacts

Current consumption (5 V system supply) 80mA

Isolation 500 V system/field

Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2


In Stock Wago 750-461 2-channel analog input for Pt100/RTD resistance sensors
