In Stock Hirschmann OZD Profi 12M G12 942148002 interface converter electrical/optical for PROFIBUS-field bus networks

In Stock Hirschmann OZD Profi 12M G12 942148002 interface converter electrical/optical for PROFIBUS-field bus networks

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Product description

Type:OZD Profi 12M G12

Name:OZD Profi 12M G12

Part Number:942148002

Port type and quantity:2 x optical: 4 sockets BFOC 2.5 (STR); 1 x electrical: Sub-D 9-pin, female, pin assignment according to EN 50170 part 1

Signal Type:PROFIBUS (DP-V0, DP-V1, DP-V2 und FMS)

More Interfaces

Power Supply:8-pin terminal block, screw mounting

Signaling contact:8-pin terminal block, screw mounting

Network size - length of cable

Single mode fiber (SM) 9/125 µm:-

Multimode fiber (MM) 50/125 µm:3000 m, 13 dB link budget at 860 nm; A = 3 dB/km, 3 dB reserve

Multimode fiber (MM) 62.5/125 µm:3000 m, 15 dB link budget at 860 nm; A = 3.5 dB/km, 3 dB reserve

Multimode fiber HCS (MM) 200/230 µm:1000 m, 18 dB link budget at 860 nm; A = 8 dB/km, 3 dB reserve

Multimode fiber POF (MM) 980/1000 µm:-

Power requirements

Current consumption:max. 190 mA

Input voltage range:-7 V ... +12 V

Operating Voltage:18 ... 32 VDC, typ. 24 VDC

Power consumption:4.5 W

Redundancy functions:HIPER-Ring (ring structure), redundant 24 V infeed

Power Output

Output voltage/output current (pin6):5 VDC +5%, -10%, short circuit-proof/10 mA

Ambient conditions

Operating temperature:0-+60 °C

Storage/transport temperature:-40-+70 °C

Relative humidity (non-condensing):10-95 %

Mechanical construction

Dimensions (WxHxD):39.5 x 137.5 x 84 mm

Weight:560 g

Housing Material:die-cast zink

Mounting:DIN rail or mounting plate

Protection class:IP40

Approvals

Basis Standard:EU Conformity, FCC Conformity, AUS Conformity Australia

Safety of industrial control equipment:cUL61010-2-201

Hazardous locations:ISA 12.12.01 Class 1 Div. 2, ATEX Zone 2

Scope of delivery and accessories

Scope of delivery:device, start-up instructions

In Stock Hirschmann OZD Profi 12M G12 942148002 interface converter electrical/optical for PROFIBUS-field bus networks

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Similar model numbers:

OZD Profi 12M G11

OZD Profi 12M G12

OZD Profi 12M G22

OZD Profi 12M G11-1300

OZD Profi 12M G12-1300

OZD Profi 12M G22-1300

OZD Profi 12M P11

OZD Profi 12M P12

OZD Profi 12M P22

OZD Profi 12M G12 EEC

OZD Profi 12M G22 EEC

OZD Profi 12M G12-1300 EEC

OZD Profi 12M G22-1300 EEC

OZD Profi 12M P12 PRO

OZD Profi 12M G11 PRO

OZD Profi 12M G12 PRO

OZD Profi 12M G11-1300 PRO

OZD Profi 12M G12-1300 PRO

OZD Profi 12M G12 EEC PRO
