Festo DGC-K-25-600-PPV-A-GK 1312501 Linear actuator

News May 18, 2023

Festo DGC-K-25-600-PPV-A-GK 1312501 Linear actuator

DGC-K-25-600-PPV-A-GK (1).JPG

DGC-K-25-600-PPV-A-GK (2).JPG

Festo DGC-K-25-600-PPV-A-GK 1312501 Linear actuator

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Stroke

1 mm ... 8500 mm

Piston diameter

25 mm

Cushioning

Pneumatic cushioning, adjustable at both ends

Mounting position

Any

Position sensing

For proximity sensor

Variants

Supply port at both ends

Standard piston

Extended piston

Operating pressure

0.2 MPa ... 0.8 MPa

Operating pressure

2 bar ... 8 bar

Mode of operation

Double-acting

CE marking (see declaration of conformity)

as per EU explosion protection directive (ATEX)

UKCA marking (see declaration of conformity)

acc. to UK EX instructions

Explosion prevention and protection

Zone 1 (ATEX)

Zone 2 (ATEX)

Zone 22 (ATEX)

ATEX category gas

II 2G

ATEX category for dust

II 3D

Type of ignition protection for gas

Ex h IIC T4 Gb X

Type of (ignition) protection for dust

Ex h IIIC T120°C Dc X

Explosive ambient temperature

-10°C <= Ta <= +60°C

Operating medium

Compressed air as per ISO 8573-1:2010 [7:-:-]

Information on operating and pilot media

Operation with oil lubrication possible (required for further use)

Corrosion resistance class (CRC)

1 - Low corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

For use in the food industry

See supplementary material information

Ambient temperature

-10 °C ... 60 °C

Cushioning length

18 mm

Theoretical force at 6 bar, retracting

295 N

Theoretical force at 6 bar, advancing

295 N

Alternative connections

See product drawing

Type of mounting

With accessories

Note on materials

RoHS-compliant

Cover material

Die-cast aluminum

Seals material

NBR

TPE-U(PU)
