Serial Interface

No. of Ports

2

Serial Standards

RS-232

RS-422

RS-485

Baudrate

50 bps to 921.6 kbps (supports non-standard baudrates)

Flow Control

ADDC (automatic data direction control) for RS-485

Optical Fiber

Pull High/Low Resistor for RS-485

1 kilo-ohm, 150 kilo-ohms

RS-485 Data Direction Control

ADDC (automatic data direction control)

Terminator for RS-485

N/A, 120 ohms, 120 kilo-ohms

Connector

Single-mode ST connector

Latency

300 ns

In Stock MOXA TCF-142-S-ST Serial-to-Fiber Converters

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Serial Signals

RS-232

TxD, RxD, GND

RS-422

Tx+, Tx-, Rx+, Rx-, GND

RS-485-4w

Tx+, Tx-, Rx+, Rx-, GND

RS-485-2w

Data+, Data-, GND

Power Parameters

No. of Power Inputs

1

Input Current

70 to 140 mA @ 12 to 48 VDC

Input Voltage

12 to 48 VDC

Overload Current Protection

Supported

Power Connector

Terminal block

Power Consumption

70 to 140 mA @ 12 to 48 VDC

Reverse Polarity Protection

Supported

Physical Characteristics

IP Rating

IP30

Housing

Metal

Dimensions (with ears)

90 x 100 x 22 mm (3.54 x 3.94 x 0.87 in)

Dimensions (without ears)

67 x 100 x 22 mm (2.64 x 3.94 x 0.87 in)

Weight

320 g (0.71 lb)

Installation

Wall mounting

In Stock MOXA TCF-142-S-ST Serial-to-Fiber Converters

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environmental Limits

Operating Temperature

0 to 60°C (32 to 140°F)

Storage Temperature (package included)

-40 to 85°C (-40 to 185°F)

Ambient Relative Humidity

5 to 95% (non-condensing)

Standards and Certifications

EMC

EN 55032/35

EMI

CISPR 32, FCC Part 15B Class A

EMS

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV

IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m

IEC 61000-4-4 EFT: Power: 1 kV

IEC 61000-4-5 Surge: Power: 1 kV

IEC 61000-4-6 CS: 3 V

IEC 61000-4-8 PFMF

Environmental Testing

IEC 60068-2-1

IEC 60068-2-2

IEC 60068-2-3

Safety

UL 60950-1

Vibration

IEC 60068-2-6

MTBF

Time

780,480 hrs

Standards

Telcordia (Bellcore), GB

In Stock MOXA TCF-142-S-ST Serial-to-Fiber Converters

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Similar model numbers:

TCF-142-M-SC

TCF-142-M-SC-T

TCF-142-M-ST

TCF-142-M-ST-T

TCF-142-S-SC

TCF-142-S-SC-T

TCF-142-S-ST

TCF-142-S-ST-T
