In Stock Schneider Electric GV2P07 Motor circuit breaker, TeSys Deca, 3P, 1.6 to 2.5A, thermal magnetic, screw clamp terminals, rotary handle

In Stock Schneider Electric GV2P07 Motor circuit breaker, TeSys Deca, 3P, 1.6 to 2.5A, thermal magnetic, screw clamp terminals, rotary handle

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range TeSys Deca

Product name TeSys GV2

TeSys Deca

Product or component type Motor circuit breaker

Device short name GV2P

Device application Motor protection

Trip unit technology Thermal-magnetic

Complementary

Poles description 3P

Network type AC

Utilisation category Category A conforming to IEC 60947-2

AC-3 conforming to IEC 60947-4-1

Network frequency 50/60 Hz conforming to IEC 60947-4-1

Fixing mode 35 mm symmetrical DIN rail: clipped

Panel: screwed (with 2 x M4 screws)

Motor power kW 0.75 kW at 400/415 V AC 50/60 Hz

1.1 kW at 500 V AC 50/60 Hz

1.5 kW at 690 V AC 50/60 Hz

Breaking capacity 100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2

100 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2

100 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2

100 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2

8 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2

[Ics] rated service short-circuit breaking capacity 100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2

100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2

100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2

100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2

100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2

Control type Rotary handle

[In] rated current 2.5 A

Thermal protection adjustment range 1…1.6 A conforming to IEC 60947-4-1

Magnetic tripping current 33.5 A

[Ith] conventional free air thermal current 2.5 A conforming to IEC 60947-4-1

[Ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-2

[Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2

[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2

Phase failure sensitivity Yes conforming to IEC 60947-4-1

Suitability for isolation Yes conforming to IEC 60947-1 § 7-1-6

Power dissipation per pole 2.5 W

Mechanical durability 100000 cycles

Electrical durability 100000 cycles for AC-3 at 415 V In

Rated duty Continuous conforming to IEC 60947-4-1

Tightening torque 1.7 N.m - on screw clamp terminal

Width 45 mm

Height 89 mm

Depth 97 mm

Colour Dark grey

Environment

Standards EN/IEC 60947-2

EN/IEC 60947-4-1

Product certifications CCC

UL

CSA

EAC

ATEX

LROS (Lloyds register of shipping)

BV

RINA

DNV-GL

UKCA

IK degree of protection IK04

IP degree of protection IP20 conforming to IEC 60529

Climatic withstand Conforming to IACS E10

Ambient air temperature for storage -40…80 °C

Fire resistance 960 °C conforming to IEC 60695-2-11

Ambient air temperature for operation -20…60 °C

Mechanical robustness Shocks: 30 Gn for 11 ms

Vibrations: 5 Gn, 5...150 Hz

Operating altitude 2000 m

Packing Units

Unit Type of Package 1 PCE

Number of Units in Package 1 1

Package 1 Height 5.000 cm

Package 1 Width 9.000 cm

Package 1 Length 10.000 cm

Package 1 Weight 330.000 g

Unit Type of Package 2 S02

Number of Units in Package 2 20

Package 2 Height 15.000 cm

Package 2 Width 30.000 cm

Package 2 Length 40.000 cm

Package 2 Weight 6.851 kg

Unit Type of Package 3 P06

Number of Units in Package 3 320

Package 3 Height 75.000 cm

Package 3 Width 80.000 cm

Package 3 Length 60.000 cm

Package 3 Weight 117.616 kg
