In Stock Schneider Electric RGZE1S48M Socket with clamp, Harmony, for RXG2 relays, 5A, screw connectors, separate contact

In Stock Schneider Electric RGZE1S48M Socket with clamp, Harmony, for RXG2 relays, 5A, screw connectors, separate contact

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of product Harmony Electromechanical Relays

Product or component type Socket

Contact terminal arrangement Separate

Complementary

Product compatibility Plug-in relay RXG with 2 C/O contact

[Ui] rated insulation voltage 250 V

[Uimp] rated impulse withstand voltage 6 kV between coil and contact with reinforced insulation

4 kV between contacts with basic insulation

4 kV between poles with basic insulation

4 kV between terminals and DIN rail with basic insulation

[In] rated current 5 A

[Ue] rated operational voltage 250 V conforming to IEC

300 V conforming to UL

Dielectric strength 5 kV between coil and contact with reinforced insulation

2.5 kV between contacts with basic insulation

3 kV between poles with basic insulation

3 kV between terminals and DIN rail with basic insulation

Connections - terminals Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 22...AWG 14) flexible with cable end

Screw terminals, 2 x 0.25...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end

Screw terminals, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end

Screw terminals, 1 x 0.5...1 x 2.5 mm² (AWG 20...AWG 14) solid without cable end

Screw type M3

Environment

Ambient air temperature for storage -40…85 °C

Ambient air temperature for operation -40…70 °C

Relative humidity 10…85 %

Standards CSA C22.2 No 14

IEC 61984

UL 508

Product certifications EAC

CE

CSA

UL

DNV-GL

IP degree of protection IP20

Overvoltage category III

Pollution degree 3

Packing Units

Unit Type of Package 1 PCE

Number of Units in Package 1 1

Package 1 Height 6.15 cm

Package 1 Width 1.6 cm

Package 1 Length 8 cm

Package 1 Weight 39.7 g

Unit Type of Package 2 BB1

Number of Units in Package 2 10

Package 2 Height 7.8 cm

Package 2 Width 8.4 cm

Package 2 Length 16.3 cm

Package 2 Weight 445 g

Unit Type of Package 3 S03

Number of Units in Package 3 180

Package 3 Height 30 cm

Package 3 Width 30 cm

Package 3 Length 40 cm

Package 3 Weight 8.648 kg
