In Stock Beckhoff EL6631 EtherCAT Terminal, 2-port communication interface, PROFINET RT, controller

In Stock Beckhoff EL6631 EtherCAT Terminal, 2-port communication interface, PROFINET RT, controller

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Technical dataEL6631

TechnologyPROFINET RT

Number of ports/channels2 (switched)

Ethernet interface100BASE-TX Ethernet with 2 x RJ45

FieldbusPROFINET RT controller

Max. process data size1 kbyte input/1 kbyte output data

Cable lengthup to 100 m twisted pair

Hardware diagnosticsstatus LEDs

Power supplyvia the E-bus

Electrical isolation500 V (E-bus/Ethernet)

ProtocolRT

Configurationvia EtherCAT master

Current consumption E-bustyp. 400 mA

Special featuresLLDP, SNMP,

Conformance Class B,

max. 15 RT devices,

min. 1 ms RT cycle

Weightapprox. 75 g

Operating/storage temperature0…+55 °C/-25…+85 °C

Relative humidity95 %, no condensation

Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27

EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4

Protect. rating/installation pos.IP20/see documentation

Approvals/markingsCE, UL, ATEX, IECEx

Ex markingATEX:

II 3 G Ex nA IIC T4 Gc

IECEx:

Ex ec IIC T4 Gc
