ABB DDA202 A-25/0.03 2CSB202101R1250 Residual Current Device Block

ABB DDA202 A-25/0.03 2CSB202101R1250 Residual Current Device Block

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Technical

Standards:IEC/EN 61009 Ann. G

Type of Residual Current:A type

Rated Voltage (Ur):230/400 V

Rated Operational Voltage:230 V

Rated Insulation Voltage (Ui):500 V

Rated Impulse Withstand Voltage (Uimp):4 kV

Rated Current (In):25 A

Rated Residual Current:30 mA

Leakage Current Type:A

Rated Frequency (f):50 … 60 Hz

Power Loss:2 W

Power Supply Connection:Arbitrary

Electrical Endurance:10000 cycle

Number of Poles:2

Operating Characteristic:Instantaneous

Options Provided:-

Connecting Capacity:Rigid 25 ... 25 mm²

Flexible 25 ... 25 mm²

Environmental

Ambient Temperature:-25...55 °C

Ambient Air Temperature:Operation -25...55 °C

Degree of Protection:IP2X

Resistance to Vibrations acc. to IEC 60068-2-6:0.1 mm or 1 g - 20 cycles at 5…150…5 Hz

Resistance to Shock acc. to IEC 60068-2-27:25g 2 shocks 13 ms

RoHS Status:Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Environmental Information:Refer to RoHS

Technical UL/CSA

Short-Circuit Current Rating (SCCR):0.03 ... 0.03 A

ABB DDA202 A-25/0.03 2CSB202101R1250 Residual Current Device Block

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Dimensions

Product Net Width:70 mm

Product Net Height:93 mm

Product Net Depth / Length:76 mm

Product Net Weight:0.210 kg

Container Information

Package Level 1 Units:box 1 piece

Package Level 1 Width:79 mm

Package Level 1 Height:80 mm

Package Level 1 Depth / Length:104 mm

Package Level 1 Gross Weight:0.245 kg

Package Level 1 EAN:8012542795414

Ordering

Minimum Order Quantity:1 piece

Customs Tariff Number:85363030

E-Number (Finland):3259826

Country of Origin:Italy (IT)

Certificates and Declarations (Document Number)

Declaration of Conformity - CE:9AKK106713A5614

Environmental Information:Refer to RoHS

Instructions and Manuals:9AKK108467A7091

RoHS Information:9AKK106713A5614

Popular Downloads

Data Sheet, Technical Information:9AKK107991A8329

Instructions and Manuals:9AKK108467A7091

Classifications

ETIM 7:EC002297 - Residual current circuit breaker (RCCB) module

ETIM 8:EC002297 - Residual current circuit breaker (RCCB) module

WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)

WEEE B2C / B2B:Business To Consumer

CN8:85363030

UNSPSC:39121601

eClass:V11.0 : 27142210

IDEA Granular Category Code (IGCC):4875 >> Residual current circuit breaker (RCCB)

Object Classification Code:F
