Siemens 6DR5220-0EG20-0AA2 SIPART PS2 smart electropneumatic positioner for pneumatic linear and part-turn actuators; 2-,3-,4-wire; 4...20mA with HART-interface

Siemens 6DR5220-0EG20-0AA2 SIPART PS2 smart electropneumatic positioner for pneumatic linear and part-turn actuators; 2-,3-,4-wire; 4...20mA with HART-interface

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Product

Article Number (Market Facing Number) 6DR5220-0EG00-0AA2

Product Description SIPART PS2 smart electropneumatic positioner for pneumatic linear and part-turn actuators; 2-,3-,4-wire; 4...20mA with HART-interface; double action; polycarbonate enclosure Standard Type of protection (Ex): Intrinsic safety (Ex i). Output isolator SITRANS I200 separately orderable (7NG4131-1AA00). Connection thread el.: M20x1.5 / pneu.: G 1/4 Without limit monitor. Without option module. . Brief instructions English / German / Chinese. Standard / Fail-Safe - Depressurizing the actuator in case of failure of electrical auxiliary power (single acting only). Manometer block aluminumG¼, double-acting with plastic manometer IP31 (MPa, bar)

Product family SIPART PS2

Product Lifecycle (PLM) PM300:Active Product

Price data

Price Group / Headquarter Price Group 8V1

List Price Show prices

Customer Price Show prices

Metal Factor None

Delivery information

Export Control Regulations ECCN : N / AL : N

Standard lead time ex-works 6 Day/Days

Net Weight (kg) 1.570 Kg

Package size unit of measure Not available

Quantity Unit 1 Piece

Packaging Quantity 1

Additional Product Information

EAN Not available

UPC Not available

Commodity Code Not available

LKZ_FDB/ CatalogID FI01-5

Product Group 4759

Group Code R3P0

Country of origin France

Compliance with the substance restrictions according to RoHS directive Since: 31/12/16

Product class C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit.

WEEE (2012/19/EU) Take-Back Obligation Yes

REACH Art. 33 Duty to inform according to the current list of candidates

Reach Information
