In Stock Mitsubishi Electric FR-CS84-080-60 Inverter Rated Power: 3,7kW 3x380-480V Rated Current: 8A IP20

News February 10, 2023

In Stock Mitsubishi Electric FR-CS84-080-60 Inverter Rated Power: 3,7kW 3x380-480V Rated Current: 8A IP20

FR-CS84-080-60 (1).JPG

FR-CS84-080-60 (2).JPG

In Stock Mitsubishi Electric FR-CS84-080-60 Inverter Rated Power: 3,7kW 3x380-480V Rated Current: 8A IP20

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Series FR-CS80 SERIES

Type FR-CS84 COMPACT INVERTER

Minimum Rated Voltage (V) 380

Min. Permissible Voltage (V) 323

Maximum Rated Voltage (V) 480

Max. Permissible Voltage (V) 550

Current Type AC

Phases 3

Rated Output Current ND (A) 8

Rated Motor Capacity ND (kW) 3,7

Control Method ADVANCED MAGN. FLUX VEC. CTRL

Motor Type INDUCTION MOTOR

Integrated EMC Filter NO

Safe Torque Off (STO) NO

Regenerative (4Q) NO

Display FR-LU08

PLC Function NO

Integrated Analogue Outputs 0

RS-485 1

Power Loss ND (W) 120

Frequency Range (Hz) 0,2–400

Integrated DC Choke NO

Display Type 4 DIGITS LED

Integrated Digital Inputs 5

Digital Outputs (Transistor) 1

Digital Outputs (Relay) 0

Integrated Analogue Inputs 2

IO Type of Terminal Block SPRING CLAMP

Expandable YES

USB NO

Ethernet Port NO

Built-In Network MODBUS-RTU

Leakage Current (mA) 1

Protection Class IP20

Product Dimensions & Weight

Width (mm) 108

Height (mm) 96

Depth (mm) 160

Weight (kg) 1,4


In Stock Mitsubishi Electric FR-CS84-080-60 Inverter Rated Power: 3,7kW 3x380-480V Rated Current: 8A IP20

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Similar model numbers:

FR-CS82S-042-60

FR-CS82S-025-60

FR-CS84-050-60

FR-CS84-036-60

FR-CS82S-070-60

FR-CS82S-100-60

FR-CS84-080-60

FR-CS84-022-60

FR-CS84-012-60

FR-CS84-120-60

FR-CS84-160-60

FR-CS84-295-60

FR-CS84-230-60
