Schneider ZBVB5 Light block for head 22mm, Harmony XB4, orange, integral LED, 24V AC DC

Schneider ZBVB5 Light block for head 22mm, Harmony XB4, orange, integral LED, 24V AC DC

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productHarmony XB4

Harmony XB5

Product or component typeLight block

Device short nameZBV

Sale per indivisible quantity5

connections - terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1

Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1

Signalling typeSteady

Light sourceProtected LED

Bulb baseIntegral LED

light block supplyDirect

Light source colourOrange

[Us] rated supply voltage24 V AC/DC at 50/60 Hz

Complementary

Product weight0.017 kg

tightening torque0.8…1.2 N.m conforming to EN 60947-1

shape of screw headCross compatible with Philips no 1 screwdriver

Cross compatible with pozidriv No 1 screwdriver

Slotted compatible with flat Ø 4 mm screwdriver

Slotted compatible with flat Ø 5.5 mm screwdriver

supply voltage limits19.2…30 V DC

21.6…26.4 V AC

Current consumption18 mA

service life100000 h at rated voltage and 25 °C

surge withstand1 kV conforming to IEC 61000-4-5

Mounting of blockFront mounting

electrical composition codeM1

M2

M3

M4

M5

M6

M10

MF1

P1

P2

PF1

Device presentationBasic element

Schneider ZBVB5 Light block for head 22mm, Harmony XB4, orange, integral LED, 24V AC DC

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient air temperature for storage-40…70 °C

Ambient air temperature for operation-40…70 °C

IP degree of protectionIP20 conforming to IEC 60529

StandardsJIS C8201-5-1

EN/IEC 60947-1

EN/IEC 60947-5-4

UL 508

EN/IEC 60947-5-5

CSA C22.2 No 14

EN/IEC 60947-5-1

JIS C8201-1

Product certificationsUL listed

CSA

resistance to fast transients2 kV conforming to IEC 61000-4-4

resistance to electromagnetic fields10 V/m conforming to IEC 61000-4-3

resistance to electrostatic discharge6 kV on contact (on metal parts) conforming to IEC 61000-4-2

8 kV in free air (in insulating parts) conforming to IEC 61000-4-2

electromagnetic emissionClass B conforming to IEC 55011

[Us] rated supply voltage24 V

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height4.4 cm

Package 1 Width5.4 cm

Package 1 Length5.6 cm

Package 1 Weight10.0 g

Unit Type of Package 2BB1

Number of Units in Package 25

Package 2 Height4.4 cm

Package 2 Width5.4 cm

Package 2 Length5.6 cm

Package 2 Weight51.0 g

Unit Type of Package 3S03

Number of Units in Package 3800

Package 3 Height30.0 cm

Package 3 Width30.0 cm

Package 3 Length40.0 cm

Package 3 Weight8.756 kg
