Schneider ZB5AV053 Head for pilot light, Harmony XB5, plastic, orange, 22mm, universal LED, plain lens

Schneider ZB5AV053 Head for pilot light, Harmony XB5, plastic, orange, 22mm, universal LED, plain lens

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productHarmony XB5

Product or component typeHead for pilot light

Product compatibilityUniversal LED

Device short nameZB5

Bezel materialDark grey plastic

Mounting diameter22 mm

Head typeStandard

Sale per indivisible quantity1

Shape of signaling unit headRound

Cap/operator or lens colourYellow

Operator additional informationWith plain lens

Complementary

CAD overall width29 mm

CAD overall height29 mm

CAD overall depth31 mm

Product weight0.017 kg

station nameXALD 1...5 cut-outs

XALK 2...5 cut-outs

electrical composition codeP1 in front mounting with integral LED

P2 in front mounting with integral LED and transformer

PF1 in front mounting with integral LED

PR1 in rear mounting with integral LED

Device presentationBasic element

Schneider ZB5AV053 Head for pilot light, Harmony XB5, plastic, orange, 22mm, universal LED, plain lens

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient air temperature for storage-40…70 °C

Ambient air temperature for operation-40…70 °C

overvoltage categoryClass II conforming to IEC 60536

IP degree of protectionIP66 conforming to IEC 60529

IP67 conforming to IEC 60529

IP69 conforming to IEC 60529

IP69K conforming to ISO 20653

NEMA degree of protectionNEMA 13

NEMA 4X

resistance to high pressure washer7000000 Pa at 55 °C, distance : 0.1 m

IK degree of protectionIK05 conforming to IEC 50102

standardsEN/IEC 60947-5-4

JIS C8201-5-1

EN/IEC 60947-5-5

EN/IEC 60947-1

CSA C22.2 No 14

EN/IEC 60947-5-1

UL 508

JIS C8201-1

vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6

shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27

50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height4.5 cm

Package 1 Width3.4 cm

Package 1 Length5.4 cm

Package 1 Weight16.0 g

Unit Type of Package 2S03

Number of Units in Package 2300

Package 2 Height30 cm

Package 2 Width30 cm

Package 2 Length40 cm

Package 2 Weight5.32 kg
