Main

Range of productHarmony XB5

Product or component typeHead for emergency stop push-button

Product destinationEmergency stop push-button

Device short nameZB5

Bezel materialDark grey plastic

Head typeStandard

Mounting diameter22 mm

Sale per indivisible quantity1

Shape of signaling unit headRound

type of operatorTrigger action and mechanical latching

ResetTurn to release

operator profileRed mushroom Ø 40 mm, unmarked

Device presentationBasic element

Complementary

CAD overall width40 mm

CAD overall height40 mm

CAD overall depth57 mm

Product weight0.046 kg

Mechanical durability300000 cycles

station nameXALD 1 cut-out

XALK 1 cut-out

electrical composition codeC7 for <4 contacts using single blocks in front mounting

C8 for <4 contacts using single and double blocks in front mounting

C11 for <3 contacts using single blocks in front mounting

C15 for <1 contacts using single blocks in front mounting

SF1 for <3 contacts using single blocks in front mounting

SR1 for <3 contacts using single blocks in rear mounting

C10 for <4 contacts using single and double blocks in front mounting

Compatibility codeZB5

Schneider ZB5AS844 Emergency stop head, Harmony XB5, switching off, plastic, red mushroom 40mm, 22mm, trigger and latching turn to release

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient air temperature for storage-40…70 °C

Ambient air temperature for operation-40…70 °C

overvoltage categoryClass II conforming to IEC 60536

IP degree of protectionIP66 conforming to IEC 60529

IP67

IP69

IP69K

NEMA degree of protectionNEMA 13

NEMA 4X

resistance to high pressure washer7000000 Pa at 55 °C, distance : 0.1 m

IK degree of protectionIK03 conforming to IEC 50102

standardsUL 508

EN/ISO 13850

IEC 60364-5-53

EN/IEC 60204-1

GB 14048.5

JIS C8201-5-1

EN/IEC 60947-5-4

CSA C22.2 No 14

EN/IEC 60947-5-5

EN/IEC 60947-1

EN/IEC 60947-5-1

JIS C8201-1

Product certificationsCSA

DNV

LROS (Lloyds register of shipping)

UL listed

GL

BV

vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6

shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27

50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height5.4 cm

Package 1 Width4.4 cm

Package 1 Length8.8 cm

Package 1 Weight42.0 g

Unit Type of Package 2S03

Number of Units in Package 2100

Package 2 Height30.0 cm

Package 2 Width30.0 cm

Package 2 Length40.0 cm

Package 2 Weight4.68 kg

Unit Type of Package 3P06

Number of Units in Package 3800

Package 3 Height77.0 cm

Package 3 Width80.0 cm

Package 3 Length60.0 cm

Package 3 Weight47.804 kg
