Schneider ZB5-AD3C Harmony XB5, Selector switch head, plastic, black, Ø22, 3 positions, stay put, grey bezel modif image

Schneider ZB5-AD3C Harmony XB5, Selector switch head, plastic, black, Ø22, 3 positions, stay put, grey bezel modif image

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of ProductHarmony XB5

Product or Component TypeHead for selector switch

Device short nameZB5

Bezel materialPlastic colour plated grey

Mounting diameter0.87 in (22 mm)

Head typeStandard

Sale per indivisible quantity1

Shape of signaling unit headRound

type of operatorStay put

operator profileBlack standard handle

Operator position information3 positions +/- 45°

Complementary

CAD overall width1.14 in (29 mm)

CAD overall height1.14 in (29 mm)

CAD overall depth1.81 in (46 mm)

Product Weight0.04 lb(US) (0.017 kg)

Mechanical durability1000000 cycles

station nameXALD 1...5 cut-outs

XALK 2...5 cut-outs

electrical composition codeC3 6 single front mounting

C4 6 single and double front mounting

C5 5 single front mounting

C6 5 single and double front mounting

C7 4 single front mounting

C8 4 single and double front mounting

C11 3 single front mounting

SF1 3 single front mounting

SR1 3 single rear mounting

Device presentationBasic element

Schneider ZB5-AD3C Harmony XB5, Selector switch head, plastic, black, Ø22, 3 positions, stay put, grey bezel modif image

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient Air Temperature for Storage-40…158 °F (-40…70 °C)

Ambient air temperature for operation-40…158 °F (-40…70 °C)

overvoltage categoryClass II IEC 60536

IP degree of protectionIP67 IEC 60529

NEMA degree of protectionNEMA 13

NEMA 4X

resistance to high pressure washer1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m

IK degree of protectionIK06 IEC 50102

Product CertificationsLROS (Lloyds register of shipping)

DNV

GL

UL Listed

BV

CSA

vibration resistance5 gn 2…500 Hz)IEC 60068-2-6

shock resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-27

50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Ordering and shipping details

Category22467-PUSHBUTTONS,22MM(PLASTIC) NEW

Discount ScheduleCS2

GTIN3606489763329

ReturnabilityNo

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height1.65 in (4.2 cm)

Package 1 Width1.30 in (3.3 cm)

Package 1 Length2.05 in (5.2 cm)

Package 1 Weight0.85 oz (24.0 g)
