Schneider ZB5-AA335C Push button head, Harmony XB5, plastic, flush, black, 22mm, spring return, marked DOWN ARROW, grey bezel

Schneider ZB5-AA335C Push button head, Harmony XB5, plastic, flush, black, 22mm, spring return, marked DOWN ARROW, grey bezel

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of ProductHarmony XALF

Harmony XB5

Product or Component TypeHead for non-illuminated push-button

Device short nameZB5

Bezel materialPlastic colour plated grey

Mounting diameter0.87 in (22 mm)

Head typeStandard

Sale per indivisible quantity1

Shape of signaling unit headRound

type of operatorSpring return

operator profileBlack flush, down arrow white)

Complementary

CAD overall width1.14 in (29 mm)

CAD overall height1.14 in (29 mm)

CAD overall depth1.10 in (28 mm)

Product Weight0.04 lb(US) (0.018 kg)

Mechanical durability10000000 cycles

station nameXALD 1...5 cut-outs

XALK 2...5 cut-outs

electrical composition codeC1 9 single front mounting

C2 9 single and double front mounting

C11 3 single front mounting

C15 1 single front mounting

SF1 3 single front mounting

SR1 3 single rear mounting

Schneider ZB5-AA335C Push button head, Harmony XB5, plastic, flush, black, 22mm, spring return, marked DOWN ARROW, grey bezel

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient Air Temperature for Storage-40…158 °F (-40…70 °C)

Ambient air temperature for operation-40…158 °F (-40…70 °C)

overvoltage categoryClass II IEC 60536

IP degree of protectionIP66 IEC 60529

IP67

NEMA degree of protectionNEMA 13

NEMA 4X

resistance to high pressure washer1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m

IK degree of protectionIK03 IEC 50102

StandardsEN/IEC 60947-1

UL 508

CSA C22.2 No 14

EN/IEC 60947-5-1

JIS C8201-5-1

EN/IEC 60947-5-4

JIS C8201-1

Product CertificationsUL Listed

CSA

BV

GL

DNV

LROS (Lloyds register of shipping)

shock resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-27

50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

vibration resistance5 gn 2…500 Hz)IEC 60068-2-6

Ordering and shipping details

Category22467-PUSHBUTTONS,22MM(PLASTIC) NEW

Discount ScheduleCS2

GTIN3606489762162

ReturnabilityNo

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height1.65 in (4.2 cm)

Package 1 Width1.30 in (3.3 cm)

Package 1 Length2.05 in (5.2 cm)

Package 1 Weight0.56 oz (16.0 g)
