Schneider ZB5-AA334C Push button head, Harmony XB5, plastic, flush, white, 22mm, spring return, marked UP ARROW, grey bezel

Schneider ZB5-AA334C Push button head, Harmony XB5, plastic, flush, white, 22mm, spring return, marked UP ARROW, grey bezel

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productHarmony XB5

Harmony XALF

Product or component typeHead for non-illuminated push-button

Device short nameZB5

Bezel materialPlastic colour plated grey

Mounting diameter22 mm

Head typeStandard

Sale per indivisible quantity1

Shape of signaling unit headRound

type of operatorSpring return

operator profileWhite flush, up arrow (black)

Complementary

CAD overall width29 mm

CAD overall height29 mm

CAD overall depth28 mm

Product weight0.018 kg

Mechanical durability10000000 cycles

station nameXALD 1...5 cut-outs

XALK 2...5 cut-outs

electrical composition codeC1 for <9 contacts using single blocks in front mounting

C2 for <9 contacts using single and double blocks in front mounting

C11 for <3 contacts using single blocks in front mounting

C15 for <1 contacts using single blocks in front mounting

SF1 for <3 contacts using single blocks in front mounting

SR1 for <3 contacts using single blocks in rear mounting

Schneider ZB5-AA334C Push button head, Harmony XB5, plastic, flush, white, 22mm, spring return, marked UP ARROW, grey bezel

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient air temperature for storage-40…70 °C

Ambient air temperature for operation-40…70 °C

overvoltage categoryClass II conforming to IEC 60536

IP degree of protectionIP66 conforming to IEC 60529

IP67

NEMA degree of protectionNEMA 13

NEMA 4X

resistance to high pressure washer7000000 Pa at 55 °C, distance : 0.1 m

IK degree of protectionIK03 conforming to IEC 50102

standardsJIS C8201-5-1

EN/IEC 60947-5-4

CSA C22.2 No 14

EN/IEC 60947-5-1

EN/IEC 60947-1

UL 508

JIS C8201-1

Product certificationsBV

LROS (Lloyds register of shipping)

CSA

DNV

GL

UL listed

shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27

50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height4.2 cm

Package 1 Width3.3 cm

Package 1 Length5.2 cm

Package 1 Weight17.0 g
