Pepperl+Fuchs IQH1-FP-V1 Read/write head in stock

Pepperl+Fuchs IQH1-FP-V1 Read/write head in stock

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Product Description

HF read/write head, ISO 15693, for IDENTControl

General specifications

Operating frequency13.56 MHz

Transfer rate26 kBit/s

Sensing range

Read distance0 ... 130 mm

Write distance0 ... 130 mm

Widthmax. 100 mm

UL File NumberE87056

Functional safety related parameters

MTTFd220 a

Mission Time (TM)10 a

Diagnostic Coverage (DC)0 %

Indicators/operating means

LED green/yellowgreen: power on

green flashing: read/write attempt performed

yellow: data carrier detected

Electrical specifications

Power consumption≤ 1.3 W

Supplyfrom the IDENTControl

Directive conformity

Radio equipment

Directive 2014/53/EUEN 301489-1

EN 301489-3

EN 300330

EN 62368-1

EN 50364

RoHS

Directive 2011/65/EU (RoHS)IEC/EN 63000

Standard conformity

Degree of protectionEN 60529

RFIDISO/IEC 15693-2

ISO/IEC 15693-3

ISO/IEC 18000-3

Approvals and certificates

FCC approvalThis device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

Caution:

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

KCC approvalKCC-CRI-PF1-IQH1-FP-V1

MIC approvalAC-14013

Radio approvalUSA: FCC IREIQH1-FP-V1

Ambient conditions

Ambient temperature-25 ... 70 °C (-13 ... 158 °F)

Storage temperature-40 ... 85 °C (-40 ... 185 °F)

Mechanical specifications

Housing length108.5 mm

Housing width80 mm

Housing height40 mm

Degree of protectionIP67

Connectionconnector M12 x 1

Material

HousingPBT

Basediecast aluminum

Encapsulation compoundCY 221/HY 2966

Installation

Distance between two headsMultiplex on: ≥ 100 mm

Multiplex off: ≥ 150 mm

Massapprox. 380 g
