Festo EB-145-60 Bellow cylinder 36486
Festo EB-145-60 Bellow cylinder 36486
jeff@hkxytech.com jeff@whxyauto.com +86-15072331761
•Size145
•Required installation Ø160 mm
•Stroke60 mm
•Max. height, advanced110 mm
•Max. angle of inclination20 deg
•Max. offset10 mm
•Min. installation height50 mm
•Mode of operationSingle-acting
•Symbol00991205
•Operating pressure0 bar ... 8 bar
•Operating mediumCompressed air as per ISO 8573-1:2010 [-:-:4]
•Information on operating and pilot mediaOperation with oil lubrication not possible
•Corrosion resistance class (CRC)2 - Moderate corrosion stress
•Ambient temperature-40 °C ... 70 °C
•Resetting force120 N
•Product weight900 g
•Type of mountingWith internal thread
•Pneumatic connectionG1/8
•Note on materialsRoHS-compliant
•Bellows materialNR/BR
•Housing materialSteel Galvanized
Festo EB-145-60 Bellow cylinder 36486
jeff@hkxytech.com jeff@whxyauto.com +86-15072331761
Similar model numbers:
EB-80-20
EB-80-45
EB-145-60
EB-145-100
EB-165-65
EB-165-125
EB-215-80
EB-215-155
EB-250-85
EB-250-185
EB-325-95
EB-325-215
EB-385-115
EB-385-230
