ABB DI571:S500,Digital Input Mod.8DI 230VAC DI:115-230VAC,2-wire

ABB DI571:S500,Digital Input Mod.8DI 230VAC DI:115-230VAC,2-wire

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

ABB Type Designation:DI571

Ambient Air Temperature:Operation 0 ... +60 °C

Storage -40 ... +70 °C

CN8:85371091

Connection Type:Pluggable

Country of Origin:China (CN)

Germany (DE)

Customs Tariff Number:85371091

Degree of Protection:IP20

Delay Time (τ):15 … 30 ms

EAN:6943747170237

EPLAN Catalog Tree:Electrical engineering / PLC / PLC input card digital

ETIM 7:EC001419 - PLC digital I/O-module

ETIM 8:EC001419 - PLC digital I/O-module

Gross Weight:0.19 kg

I/O Option:eCo-IO module with Onboard IO - 8DI

Input Current:8 mA

Input Voltage Type:AC

Invoice Description:DI571:S500,Digital Input Mod.8DI 230VAC

Made To Order:No

Maximum Input Voltage:0 ... 264 V

Maximum Operating Altitude Permissible:2000 m

Maximum Order Quantity:15 piece

Minimum Order Quantity:1 piece

Mounting Position:Horizontal, Vertical possible with derating

Mounting Type:DIN rail and panel mounting

Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715

Number of Digital Configurable I/Os:0

Number of Digital Inputs:8

Number of Digital Inputs AC 230V:8

Order Multiple:1 piece

Primary Voltage:24 V

Product Main Type:DI571

Product Name:Distributed Automation I/Os

Product Net Depth / Length:135 mm

Product Net Height:74 mm

Product Net Length:135 mm

Product Net Weight:0.129 kg

Product Net Width:34 mm

Product Type:PLC-AC500-eCo

Programming Software:AC500 Control Builder PS501-PROG

Quote Only:No

SCIP:d55e12cc-c96e-425b-a1c9-78af6c501e25 China (CN)

Selling Unit of Measure:piece

Short Description:DI571:S500,Digital Input Mod.8DI 230VAC

Stocked At (Warehouses):Menden, Germany

Singapore, Singapore

Hangzhou, China

UNSPSC:32151705

WEEE B2C / B2B:Business To Business

WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)

eClass:27-24-22-04

ABB DI571:S500,Digital Input Mod.8DI 230VAC DI:115-230VAC,2-wire
