Endress+Hauser Levelflex FMP53: Guided Wave Radar for Hygienic Level Measurement

FMP53 is not simply a standard level transmitter with a sanitary fitting. The complete order code determines the process connection, probe length, wetted materials, housing, communication, approvals and documentation. Correct selection should therefore start with the process, cleaning method and regulatory requirements.

Why Choose the Levelflex FMP53?

How Guided Wave Radar Works

High-frequency radar pulses travel along the rod probe. When the signal reaches the liquid surface, part of it is reflected to the transmitter. The measured travel time is converted into level. The guided signal path helps reduce the influence of vessel geometry and difficult surface conditions.

Levelflex FMP53 Key Specifications

Specifications and approvals depend on the selected order code. Confirm the current manufacturer documentation and process compatibility before ordering.

Hygienic Compliance and Documentation

Endress+Hauser states that the FMP53 meets hygiene requirements according to ASME BPE and USP Class VI. Available hygienic approvals include 3-A, EHEDG and a Certificate of Compliance to ASME BPE. Required certificates and material documentation should be specified when the instrument is ordered.

Typical Applications

• Food and beverage processing vessels
• Dairy tanks and hygienic storage systems
• Pharmaceutical and biotechnology processes
• Life sciences vessels requiring validated hygienic design
• Applications with foam, moving surfaces or changing products
• Systems filled or cleaned through spray heads

FMP52 or FMP53?

Information Needed for Correct Selection

1. Product name, dielectric constant and process characteristics
2. Tank height, nozzle position and required measuring range
3. Operating and cleaning temperature and pressure
4. Required hygienic process connection and seal arrangement
5. Required 3-A, EHEDG, ASME BPE, material or calibration documentation
6. Communication protocol, hazardous-area approval and SIL/WHG requirements

Technical reference: Endress+Hauser Levelflex FMP53 official product information. Product specifications and availability may change; confirm the complete order code before purchasing.
