In Stock Pepperl+Fuchs KFD0-RSH-1.4S.PS2 Relay Module

In Stock Pepperl+Fuchs KFD0-RSH-1.4S.PS2 Relay Module

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

General specifications

Signal typeDigital Output

Functional safety related parameters

Safety Integrity Level (SIL)SIL 3

Supply

Rated voltageloop powered

Power dissipation< 1.5 W

Power consumption< 1.5 W

Input

Connection sidecontrol side

ConnectionInput terminals 7, 8 ; test input terminals 10, 11, 12

Pulse/Pause ratiomin. 20 ms / min. 20 ms

Test inputsee functional safety manual

Signal level0-signal: -3 ... 3 V DC

1-signal: 20 ... 26.5 V

Rated current45 ... 50 mA

Output

Connection sidefield side

Connectionoutput I (ETS): terminals 2, 3

output II (DTS): terminals 4, 5, 6

output I and II (DPS): terminals 2, 3, 4, 5, 6

Contact loading253 V AC/5 A/cos φ 0.7; 30 V DC/5 A resistive load

Minimum switch current2 mA / 24 V DC

Energized/De-energized delayapprox. 10 ms / approx. 5 ms

Mechanical life5 x 106 switching cycles

Fuse rating2.5 A (max. 5 A)

recommended maximum utilization of the fuse: 80 %

Transfer characteristics

Switching frequency< 10 Hz

Galvanic isolation

Input/Outputreinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Output/Outputreinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Indicators/settings

Display elementsLEDs

Labelingspace for labeling at the front

Directive conformity

Electromagnetic compatibility

Directive 2014/30/EUEN 61326-1:2013 (industrial locations)

Low voltage

Directive 2014/35/EUEN 61010-1:2010

Conformity

Electromagnetic compatibilityNE 21:2012

Degree of protectionIEC 60529:2013

Ambient conditions

Ambient temperature-20 ... 60 °C (-4 ... 140 °F)

Observe the temperature range limited by derating, see section derating.

Mechanical specifications

Degree of protectionIP20

Connectionscrew terminals

Massapprox. 100 g

Dimensions20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2

Mountingon 35 mm DIN mounting rail acc. to EN 60715:2001
