HIRSCHMANN MACH104-20TX-F-4POE-L3P FOR INDUSTRIAL NETWORK ENGINEERING
Ordering number 942003202: 24-port managed full-Gigabit switch with 20 copper ports, four PoE ports, four combo uplinks, Layer 3 Professional software and fanless design.
CONTROL-NETWORK DESIGN
This MACH104 configuration supports compact routed PoE connectivity in 19-inch automation cabinets. Copper access ports and combo uplinks give engineers a practical way to combine local devices with fiber or copper aggregation while keeping management on one industrial platform.
ENGINEERING CHECKPOINTS
Confirm the complete ordering code and software level
Map copper, PoE or PoE+ loads before commissioning
Select SFP optics for distance and fiber type
Plan VLANs, QoS and resilient uplink paths
Verify power architecture and cabinet thermal design
Record management, alarm and backup settings
| Ordering Code | Part Number/Model | Item Description |
|---|---|---|
| Control Room Full Giga Ethernet Layer 2/3 Switch - MACH100 Family | ||
| 942003001 | MACH104-20TX-F | 19" Compact, industrial managed workgroup-Switch with 24 port Gigabit Ethernet ports (20 x GE TX Ports, 4 x GE SFP combo ports) |
| 942003002 | MACH104-20TX-F-L3P | 19" Compact, industrial managed workgroup-Switch with 24 port Gigabit Ethernet ports (20 x GE TX Ports, 4 x GE SFP combo ports),Layer3 Professional |
| 942003101 | MACH104-20TX-FR | 19" Compact, industrial managed workgroup-Switch with 24 port Gigabit Ethernet ports (20 x GE TX Ports, 4 x GE SFP combo ports). Redundant Power Supplies |
| 942003102 | MACH104-20TX-FR-L3P | 19" Compact, industrial managed workgroup-Switch with 24 port Gigabit Ethernet ports (20 x GE TX Ports, 4 x GE SFP combo ports). Redundant Power Supplies, Layer3 Professional |
| Control Room Full Giga Ethernet POE Switch - MACH100 Family | ||
| 942003201 | MACH104-20TX-F-4PoE | 19" Compact, industrial managed workgroup-Switch with 24 port Gigabit Ethernet ports (20 x GE TX Ports, 4 of which is PoE ports + 4 x GE SFP combo ports) |
| 942003202 | MACH104-20TX-F-4PoE-L3P | 24 port Gigabit Ethernet Industrial Workgroup Switch (20 x GE TX ports, there from 4 x PoE ports, 4 x GE SFP combo ports), managed, Software Layer 3 Professional, IPv6 Ready, fanless design |
| 942030001 | MACH104-16TX-PoEP | 4*GE Combo ports, 16*GE PoE+ ports, Internal Power Supply with Fan Cooling |
| 942027001 | MACH104-16TX-PoEP-E | 20 Port Gigabit Ethernet Industrial Workgroup Switch(16 x GE TX PoEPlus Ports, 4 x GE SFP combo Ports), managed, Software Layer 2 Professional, fan less Design, IPv6 Ready |
| 942027002 | MACH104-16TX-PoEP-E-L3P | 20 Port Gigabit Ethernet Industrial Workgroup Switch(16 x GE TX PoEPlus Ports, 4 x GE SFP combo Ports), managed, Software Layer 3 Professional, fan less Design, IPv6 Ready |
| 942026001 | MACH104-16TX-PoEP-R | 20 Port Gigabit Ethernet Industrial Workgroup Switch (16 x GE TX PoEPlus Ports, 4 x GE SFP combo Ports), managed, Software Layer 2 Professional, IPv6 Ready |
| 942026002 | MACH104-16TX-PoEP-R-L3P | 20 Port Gigabit Ethernet Industrial Workgroup Switch(16 x GE TX PoEPlus Ports, 4 x GE SFP combo Ports), managed, Software Layer 3 Professional, IPv6 Ready |
REQUEST PRICE, AVAILABILITY AND LEAD TIME
Email: becky@hkxytech.com
Mobile/WhatsApp/WeChat: +86 15972186287
Technical note: Confirm the complete configuration and current manufacturer documentation before purchase.
