Hirschmann industrial networking portfolio image. Confirm the exact 942170009 configuration in the quotation.

Four SFP slots are not four “spare ports”

Four optical slots can support a resilient ring plus a separate backbone connection, two independent network zones, redundant coupling between production areas, or a staged migration from one fiber standard to another. Each architecture uses the same physical switch differently. The topology must therefore be agreed before the SFP purchase order is released.

A design that buys four identical optics without defining their peers can create commissioning delays. Every link needs matching speed, wavelength, fiber type, connector, temperature class and optical budget at both ends.

Verified configuration at a glance

Specifications are based on current Belden/Hirschmann information and may change. Confirm the current datasheet, firmware, approvals and complete suffix before ordering.

A practical four-uplink planning matrix

The optical BOM is part of the switch design

Do not request “four SFPs” as a generic accessory. For each slot, record the remote device, speed, fiber type, wavelength, connector, route length, measured loss, environmental temperature and required spare strategy. Mixed multimode and single-mode links can coexist only when every individual link uses compatible optics and fiber at both ends.

942170008 or 942170009?

942170008 / BRS40-8TX is the compact all-copper option with eight Gigabit RJ45 ports. 942170009 / BRS40-8TX/4SFP keeps those eight copper ports and adds four flexible fiber slots. Choose 942170009 when optical uplinks are part of the architecture; choose 942170008 when the cabinet is intentionally copper-only. Adding media converters later can increase power, space, patching and failure points.

Eight details for a reliable RFQ

1. Quote BRS40-8TX/4SFP, the full configuration and 942170009 together.

2. State quantity, destination and required delivery date.

3. Define the purpose of all four SFP slots.

4. Provide speed, fiber type, connector and distance per link.

5. Identify remote devices and their transceiver part numbers.

6. State VLAN, redundancy, LACP, TSN and management needs.

7. Confirm power, grounding, temperature and approvals.

8. Specify operational spares and acceptable alternatives.

Frequently asked questions

Is BRS40-0012OOOO-STCY99HHSESXX.X.XX the same item as 942170009?

Yes. Use the commercial model, full configuration and order number together to reduce sourcing errors.

Are the four SFP transceivers included?

Do not assume so. The exact transceiver requirements should be listed and confirmed separately in the quotation.

Can the SFP slots use both 100 and 1000 Mbit/s?

The current specification lists 100/1000 Mbit/s SFP slots. The chosen transceivers, peer devices and configuration must support the intended rate.

Do you supply other Hirschmann BOBCAT BRS models?

Yes. The following requested models are currently hot-selling; availability and delivery are confirmed at RFQ time.
