HIRSCHMMAN BRS42-0012OOOO-TPDZ99HHSEAXX.X.XX INDUSTRIAL POE+ TSN SWITCH FOR DIN-RAIL NETWORKS
PRODUCT OVERVIEW: BRS42-0012OOOO-TPDZ99HHSEAXX.X.XX is a configurable Hirschmann BOBCAT managed Ethernet switch platform for industrial networks that need Gigabit performance, PoE+ connectivity, fiber uplinks and precise TSN-capable communication.
Built for control cabinets and distributed automation systems, the BOBCAT family combines a compact fanless DIN-rail form factor with managed Layer 2 functions, redundant power concepts and flexible copper/fiber interfaces. The complete configuration code should be used when requesting availability or a quotation because approvals, temperature range, housing and software options can differ between variants.
PRODUCT CONFIGURATION AT A GLANCE
| Order No. | 942170999 |
| Part Number / Model | BRS42-0012OOOO-TPDZ99HHSEAXX.X.XX |
| Description | Configurable BOBCAT managed industrial Ethernet switch, 12-port all-Gigabit architecture with configured PoE/PoE+ copper ports and fiber SFP connectivity, fanless DIN-rail design. |
WHY USE A HIRSCHMANN BOBCAT SWITCH?
BOBCAT switches are suited to machine automation, manufacturing cells, process plants, transportation systems, utilities and security networks. Their managed architecture supports reliable segmentation, diagnostics and redundancy, while TSN capabilities help prepare industrial Ethernet infrastructures for time-critical traffic.
Managed industrial Gigabit Ethernet connectivity
PoE/PoE+ options for compatible field devices
RJ45 copper ports with SFP fiber uplink flexibility
Compact fanless construction for DIN-rail cabinets
BOBCAT platform support for real-time TSN networking
COMPLETE BOBCAT BRS ORDERING REFERENCE
ORDERING LIST SUMMARY: The tables below contain all 101 supplied BRS20, BRS30, BRS40 and BRS50 products. Every row provides the Order No., Part Number / Model and Description required for purchasing reference.
BRS20 ORDERING MODELS (47)
| Order No. | Part Number / Model | Description |
|---|---|---|
| 942170073 | BRS20-12TX | 12x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170074 | BRS20-12TX-EEC | 12x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170053 | BRS20-16TX | 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170116 | BRS20-16TX-2A | 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170054 | BRS20-16TX-EEC | 16x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170055 | BRS20-16TX/4SFP | 4x FE SFP, 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170056 | BRS20-16TX/4SFP-EEC | 4x FE SFP, 16x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170081 | BRS20-20TX | 20x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170082 | BRS20-20TX-EEC | 20x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170057 | BRS20-20TX/4SFP | 4x FE SFP, 20x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170058 | BRS20-20TX/4SFP-EEC | 4x FE SFP, 20x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170083 | BRS20-24TX | 24x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170084 | BRS20-24TX-EEC | 24x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170001 | BRS20-4TX | 4x FE TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170103 | BRS20-4TX-2A | 4x FE TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170011 | BRS20-4TX-EEC | 4x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170034 | BRS20-4TX-EEC-HL | 4x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170023 | BRS20-4TX-HL | 4x FE TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170003 | BRS20-4TX/2FX | 4x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170105 | BRS20-4TX/2FX-2A | 4x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170013 | BRS20-4TX/2FX-EEC | 4x FE TX, 2x FE FX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170036 | BRS20-4TX/2FX-EEC-HL | 4x FE TX, 2x FE FX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170025 | BRS20-4TX/2FX-HL | 4x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170005 | BRS20-4TX/2FX-SM | 4x FE TX, 2x FE FX-SM, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170015 | BRS20-4TX/2FX-SM-EEC | 4x FE TX, 2x FE FX-SM, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170038 | BRS20-4TX/2FX-SM-EEC-HL | 4x FE TX, 2x FE FX-SM, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170027 | BRS20-4TX/2FX-SM-HL | 4x FE TX, 2x FE FX-SM, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170021 | BRS20-4TX/2SFP | 4x FE TX, 2x FE SFP, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170022 | BRS20-4TX/2SFP-EEC | 4x FE TX, 2x FE SFP, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170040 | BRS20-4TX/2SFP-EEC-HL | 4x FE TX, 2x FE SFP, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170029 | BRS20-4TX/2SFP-HL | 4x FE TX, 2x FE SFP, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170002 | BRS20-8TX | 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170104 | BRS20-8TX-2A | 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170012 | BRS20-8TX-EEC | 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170035 | BRS20-8TX-EEC-HL | 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170024 | BRS20-8TX-HL | 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170004 | BRS20-8TX/2FX | 8x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170106 | BRS20-8TX/2FX-2A | 8x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170014 | BRS20-8TX/2FX-EEC | 8x FE TX, 2x FE FX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170037 | BRS20-8TX/2FX-EEC-HL | 8x FE TX, 2x FE FX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170026 | BRS20-8TX/2FX-HL | 8x FE TX, 2x FE FX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170006 | BRS20-8TX/2FX-SM | 8x FE TX, 2x FE FX-SM, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170107 | BRS20-8TX/2FX-SM-2A | 8x FE TX, 2x FE FX-SM, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170016 | BRS20-8TX/2FX-SM-EEC | 8x FE TX, 2x FE FX-SM, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170112 | BRS20-8TX/2FX-SM-EEC-2A | 8x FE TX, 2x FE FX-SM, 12-24 V DC, -40- +70°C, HiOS L2A |
| 942170039 | BRS20-8TX/2FX-SM-EEC-HL | 8x FE TX, 2x FE FX-SM, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170028 | BRS20-8TX/2FX-SM-HL | 8x FE TX, 2x FE FX-SM, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
BRS30 ORDERING MODELS (19)
| Order No. | Part Number / Model | Description |
|---|---|---|
| 942170075 | BRS30-12TX | 4x Gig TX, 8x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170076 | BRS30-12TX-EEC | 4x Gig TX, 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170059 | BRS30-16TX/4SFP | 4x Gig SFP, 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170117 | BRS30-16TX/4SFP-2A | 4x Gig SFP, 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170060 | BRS30-16TX/4SFP-EEC | 4x Gig SFP, 16x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170118 | BRS30-16TX/4SFP-EEC-2A | 4x Gig SFP, 16x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2A |
| 942170085 | BRS30-20TX | 4x Gig TX, 16x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170086 | BRS30-20TX-EEC | 4x Gig TX, 16x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170061 | BRS30-20TX/4SFP | 4x Gig SFP, 20x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170119 | BRS30-20TX/4SFP-2A | 4x Gig SFP, 20x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170062 | BRS30-20TX/4SFP-EEC | 4x Gig SFP, 20x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170087 | BRS30-24TX | 4x Gig TX, 20x FE TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170088 | BRS30-24TX-EEC | 4x Gig TX, 20x FE TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170007 | BRS30-8TX/4SFP | 4x Gig SFP, 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170108 | BRS30-8TX/4SFP-2A | 4x Gig SFP, 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170017 | BRS30-8TX/4SFP-EEC | 4x Gig SFP, 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170113 | BRS30-8TX/4SFP-EEC-2A | 4x Gig SFP, 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2A |
| 942170041 | BRS30-8TX/4SFP-EEC-HL | 4x Gig SFP, 8x FE TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170030 | BRS30-8TX/4SFP-HL | 4x Gig SFP, 8x FE TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
BRS40 ORDERING MODELS (26)
| Order No. | Part Number / Model | Description |
|---|---|---|
| 942170077 | BRS40-12TX | 12x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170122 | BRS40-12TX-2A | 12x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170078 | BRS40-12TX-EEC | 12x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170063 | BRS40-16TX | 16x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170064 | BRS40-16TX-EEC | 16x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170065 | BRS40-16TX/4SFP | 4x Gig SFP, 16x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170120 | BRS40-16TX/4SFP-2A | 4x Gig SFP, 16x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170066 | BRS40-16TX/4SFP-EEC | 4x Gig SFP, 16x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170089 | BRS40-20TX | 20x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170090 | BRS40-20TX-EEC | 20x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170067 | BRS40-20TX/4SFP | 4x Gig SFP, 20x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170121 | BRS40-20TX/4SFP-2A | 4x Gig SFP, 20x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2A |
| 942170068 | BRS40-20TX/4SFP-EEC | 4x Gig SFP, 20x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170091 | BRS40-24TX | 24x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170092 | BRS40-24TX-EEC | 24x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170008 | BRS40-8TX | 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170109 | BRS40-8TX-2A | 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170018 | BRS40-8TX-EEC | 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170042 | BRS40-8TX-EEC-HL | 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170031 | BRS40-8TX-HL | 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
| 942170009 | BRS40-8TX/4SFP | 4x Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170110 | BRS40-8TX/4SFP-2A | 4x Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170019 | BRS40-8TX/4SFP-EEC | 4x Gig SFP, 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170114 | BRS40-8TX/4SFP-EEC-2A | 4x Gig SFP, 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2A |
| 942170043 | BRS40-8TX/4SFP-EEC-HL | 4x Gig SFP, 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170032 | BRS40-8TX/4SFP-HL | 4x Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
BRS50 ORDERING MODELS (9)
| Order No. | Part Number / Model | Description |
|---|---|---|
| 942170069 | BRS50-16TX/4SFP | 4x 2.5 Gig SFP, 16x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170070 | BRS50-16TX/4SFP-EEC | 4x 2.5 Gig SFP, 16x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170071 | BRS50-20TX/4SFP | 4x 2.5 Gig SFP, 20x Gig TX, 12-24 V DC, 0 °C to +60 °C, HiOS L2S |
| 942170072 | BRS50-20TX/4SFP-EEC | 4x 2.5 Gig SFP, 20x Gig TX, 12-24 V DC, -40 °C to +70 °C, HiOS L2S |
| 942170010 | BRS50-8TX/4SFP | 4x 2.5 Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S |
| 942170111 | BRS50-8TX/4SFP-2A | 4x 2.5 Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2A |
| 942170020 | BRS50-8TX/4SFP-EEC | 4x 2.5 Gig SFP, 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S |
| 942170044 | BRS50-8TX/4SFP-EEC-HL | 4x 2.5 Gig SFP, 8x Gig TX, 12-24 V DC, -40- +70°C, HiOS L2S, hazardous location approval |
| 942170033 | BRS50-8TX/4SFP-HL | 4x 2.5 Gig SFP, 8x Gig TX, 12-24 V DC, 0-60°C, HiOS L2S, hazardous location approval |
