In Stock Phoenix Contact QUINT-ORING/24DC/2X10/1X20 2320173 Redundancy module, with protective coating

News June 30, 2023

In Stock Phoenix Contact QUINT-ORING/24DC/2X10/1X20 2320173 Redundancy module, with protective coating



In Stock Phoenix Contact QUINT-ORING/24DC/2X10/1X20 2320173 Redundancy module, with protective coating

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Input data

DC operation

Nominal input voltage range24 V DC

Input voltage range18 V DC ... 28 V DC (SELV)

Input voltage range DC18 V DC ... 28 V DC (SELV)

Voltage type of supply voltageDC

Reverse polarity protection< yes60 V

Nominal input current (IN)2x 10 A (-25 °C ... 60 °C)

1x 20 A (-25 °C ... 60 °C)

Maximum current Imax2x 15 A (-25 °C ... 40 °C)

1x 30 A (-25 °C ... 40 °C)

60 A (12 ms, SFB Technology)

Transient surge protectionVaristor

Voltage drop, input/output0.1 V (IOUT = 20 A)


Output data

Efficiency> 98 %

Nominal output voltage0.1 V (< DC input)

Output voltageUIn -

Nominal output current (IN)20 A (Increasing power)

10 A (Redundancy)

Derating60 °C ... 70 °C (2.5%/K)

Protection against overvoltage at the output (OVP)< 32 V DC

Power loss nominal load max.2 W (IOUT = 20 A)

Connection in seriesNo

Signal: Redundancy OK, 13/14

Output descriptionGroup contact

Maximum switching voltagemax. 30 V AC/DC

Maximum inrush current≤ 100 mA (short-circuit-proof)

Signal: ACB (Auto Current Balancing) OK, 23/24

Output descriptionContact closed: Δ UIN ≤ 300 mV

Maximum switching voltagemax. 30 V AC/DC

Maximum inrush current≤ 100 mA (short-circuit-proof)


In Stock Phoenix Contact QUINT-ORING/24DC/2X10/1X20 2320173 Redundancy module, with protective coating

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761


Similar model numbers:

QUINT-ORING/24DC/2X10/1X20

QUINT-ORING/24DC/2X40/1X80

QUINT-ORING/24DC/2X20/1X40

QUINT4-S-ORING/12-24DC/1X40

QUINT4-S-ORING/12-24DC/1X40

QUINT4-S-ORING/12-24DC/1X40/VP

QUINT4-ORING/12-24DC/2X10/2X10

QUINT4-ORING/12-24DC/2X20/2X20
