In Stock Schneider Electric GVAE20 Auxiliary contact block,TeSys Deca,2NO,front mounting,for GV2

In Stock Schneider Electric GVAE20 Auxiliary contact block,TeSys Deca,2NO,front mounting,for GV2

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

RangeTeSys

TeSys Deca

Device short nameGVAE

Product or component typeAuxiliary contact block

Product compatibilityGV2L

GV3P

GV2ME

LS1D32

GV3L

GV2RT

GV2P

GV2LE

Mounting locationFront side

Pole contact composition2 NO

Quantity per setSet of 10

Complementary

[Ui] rated insulation voltage300 V conforming to UL 508

300 V conforming to CSA C22.2 No 14

250 V conforming to IEC 60947-1

[Ue] rated operational voltage24...240 V AC

24...60 V DC

[Ith] conventional free air thermal current2.5 A

Protection typeGG fuse 10 A

GB2CB06 circuit breaker 10 A

Mechanical durability100000 cycles

Minimum switching current5 mA

Minimum switching voltage17 V

Rated operational power in VA120 VA at 110…120 V AC-15 - electrical durability: 100000 cycles

120 VA at 230…240 V AC-15 - electrical durability: 100000 cycles

48 VA at 24 V AC-15 - electrical durability: 100000 cycles

60 VA at 48 V AC-15 - electrical durability: 100000 cycles

Rated operational power in W15 W at 48 V DC-13 - electrical durability: 100000 cycles

24 W at 24 V DC-13 - electrical durability: 100000 cycles

9 W at 60 V DC-13 - electrical durability: 100000 cycles

Tightening torque1.4 N.m - on screw clamp terminals

Height11 mm

Width45 mm

Depth29 mm

Net weight0.02 kg

Environment

Environmental characteristicNormal environment

Product certificationsUKCA

In Stock Schneider Electric GVAE20 Auxiliary contact block,TeSys Deca,2NO,front mounting,for GV2

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height1.600 cm

Package 1 Width5.000 cm

Package 1 Length6.000 cm

Package 1 Weight19.000 g

Unit Type of Package 2BB1

Number of Units in Package 210

Package 2 Height6.300 cm

Package 2 Width7.300 cm

Package 2 Length12.000 cm

Package 2 Weight209.000 g

Unit Type of Package 3S02

Number of Units in Package 3220

Package 3 Height15.000 cm

Package 3 Width30.000 cm

Package 3 Length40.000 cm

Package 3 Weight4.377 kg
