In Stock Schneider Electric BMXDDI3202K Discrete input module, Modicon X80, 32 inputs, 24V DC positive

In Stock Schneider Electric BMXDDI3202K Discrete input module, Modicon X80, 32 inputs, 24V DC positive

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productModicon X80

Product or component typeDiscrete input module

Discrete input number32

Discrete input typeIsolated

Input typeCurrent sink (logic positive)

Discrete input voltage24 V DC, discrete input logic: positive

Discrete input current2.5 mA

Complementary

Input compatibilityWith 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2

With 2-wire/3-wire proximity sensors conforming to IEC 61131-2 Type 1

Sensor power supply19...30 V

Current state 1 guaranteed>= 2 mA

Current state 0 guaranteed<= 0.5 mA

Input impedance9600 Ohm

Insulation resistance> 10 MOhm 500 V DC

Power dissipation in W3.9 W

DC typical response time4 ms

DC maximum response time7 ms

Paralleling of inputsNo

Typical current consumption121 mA at 3.3 V DC

MTBF reliability905000 H

Protection type1 external fuse per group of channel0.5 A fast blow

reverse polarity protection

Voltage detection threshold< 14 V DC sensor fault

> 18 V DC sensor OK

Status LED1 LED (green) module operating (RUN)

1 LED per channel (green) channel diagnostic

1 LED (red) module error (ERR)

1 LED (red) module I/O

Net weight0.112 kg

Environment

IP degree of protectionIP20

Directives2014/35/EU - low voltage directive

2014/30/EU - electromagnetic compatibility

Dielectric strength1500 V AC at 50/60 Hz 1 minute, primary/secondary

500 V DC 1 minute, between group of channels

Vibration resistance3 gn

Shock resistance30 gn

Ambient air temperature for storage-40…85 °C

ambient air temperature for operation0…60 °C

Relative humidity5…95 % at 55 °C without condensation

Operating altitude0...2000 m

2000...5000 m with derating factor

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height5.373 cm

Package 1 Width10.974 cm

Package 1 Length11.554 cm

Package 1 Weight154.4 g

Unit Type of Package 2S02

Number of Units in Package 215

Package 2 Height15.0 cm

Package 2 Width30.0 cm

Package 2 Length40.0 cm

Package 2 Weight2.5 kg
