In Stock B&R X20PS3300 24 VDC supply module for I/O and bus

In Stock B&R X20PS3300 24 VDC supply module for I/O and bus

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

General information

B&R ID code 0x1BC0

Status indicators Overload, operating state, module status

Diagnostics

Module run/error Yes, using LED status indicator and software

Overload Yes, using LED status indicator and software

Power consumption for X2X Link power supply  1.42 W

Power consumption

Internal I/O 0.6 W

Additional power dissipation caused by actuators (resistive) [W] -

Certifications

CE Yes

UKCA Yes

ATEX Zone 2, II 3G Ex nA nC IIA T5 Gc

IP20, Ta (see X20 user's manual)

FTZÚ 09 ATEX 0083X

UL cULus E115267

Industrial control equipment

HazLoc cCSAus 244665

Process control equipment

for hazardous locations

Class I, Division 2, Groups ABCD, T5

DNV Temperature: B(0 - 55°C)

Humidity: B(up to 100%)

Vibration: B(4 g)

EMC: B(bridge and open deck)

LR ENV1

KR Yes

ABS Yes

BV EC33B

Temperature: 5 - 55°C

Vibration: 4 g

EMC: Bridge and open deck

EAC Yes

KC Yes

In Stock B&R X20PS3300 24 VDC supply module for I/O and bus

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

X2X Link power supply input

Input voltage 24 VDC -15% / +20%

Input current Max. 0.7 A

Fuse Integrated, cannot be replaced

Reverse polarity protection Yes

X2X Link power supply output

Nominal output power 7 W

Parallel connection Yes

Redundant operation Yes

Overload characteristics Short-circuit proof, temporary overload

Input I/O power supply

Input voltage 24 VDC -15% / +20%

Fuse Required line fuse: Max. 10 A, slow-blow

Reverse polarity protection No

Output I/O power supply

Nominal output voltage 24 VDC

Behavior on short circuit Required line fuse

Permissible contact load 10 A

Electrical properties

Electrical isolation

X2X Link supply isolated from X2X Link power supply

I/O supply not isolated from I/O power supply

In Stock B&R X20PS3300 24 VDC supply module for I/O and bus

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Operating conditions

Mounting orientation

Horizontal Yes

Vertical Yes

Installation elevation above sea level

0 to 2000 m No limitation

>2000 m Reduction of ambient temperature by 0.5°C per 100 m

Degree of protection per EN 60529 IP20

Ambient conditions

Temperature

Operation

Horizontal mounting orientation -25 to 60°C

Vertical mounting orientation -25 to 50°C

Derating See section "Derating".

Storage -40 to 85°C

Transport -40 to 85°C

Relative humidity

Operation 5 to 95%, non-condensing

Storage 5 to 95%, non-condensing

Transport 5 to 95%, non-condensing

Mechanical properties

Note Order 1x terminal block X20TB12 separately.

Order 1x power supply bus module X20BM01 separately

Pitch 12.5+0.2mm
