In Stock Schneider Electric BMXCRA31210 remote IO drop E/IP, Modicon X80, performance, service port, advanced features

In Stock Schneider Electric BMXCRA31210 remote IO drop E/IP, Modicon X80, performance, service port, advanced features

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of product Modicon X80

Range compatibility Modicon M580

Modicon Quantum

Product or component type I/O expansion module

Device application X80 Ethernet RIO drop adaptor

Product specific application For remote I/O modules

Complementary

Bus type Bus X across the remote backplane

Number of port 3

Integrated connection type 1 port for service or distributed equipment

2 port for Ethernet RIO Network (RSTP)

Communication network type IPv4 (internet protocol)

communication port protocol EtherNet/IP

Communication service Ethernet/IP adapter

RSTP (Ring topology support)

Ethernet RIO network

Quality of Service (QoS)

CIP Explicit messaging (server)

Modbus TCP server for module diagnostics

DHCP client

TFTP client

FTP client

FDR client

SNTP client

SNMP agent

Cybersecurity Enable/disable communication ports

Syslog protocol support

Connector type 3 RJ45

Exchange mode Half duplex, full duplex, autonegotiation, auto MDIX

Transmission rate 10/100 Mbit/s

Port Ethernet 10/100BASE-TX

Function available CCOTF (configuration change on the fly)

Input data is collected and published to the remote I/O head adaptor

Output modules are updated with the data received from remote I/O head adaptor

Diagnostics for remote I/O devices (Device DDT)

Port mirroring

System time stamping

Non-interfering type 1

I/O extension rack

Data recording 10 ms time stamps

Topology Ring

Local signalling 1 LED (green) for module active (RUN)

1 LED (red) for module error (ERR)

1 LED (green/red) for module status (Mod Status)

1 LED (green/red) for network communication status (Net Status)

1 LED (green) for Ethernet link diagnostics (STS)

Current consumption 1200 mA

Input voltage 3.3 V DC

Product compatibility 0…1024 discrete channel

0…256 analog channel

counter module

time-stamping module

SSI encoder interface module

motion control module

frequency input module

AS-Interface module

serial link module

fiber converter modules

Module format Standard

Net weight 0.225 kg

Maximum altitude transport 3000 m

Relative humidity 95 % without condensation

Fixing mode By screws

Mounting mode Rack-mounted

Width 32 mm

Height 100 mm

Depth 87.5 mm

Environment

Directives 2014/35/EU - low voltage directive

2014/30/EU - electromagnetic compatibility

Product certifications CE

UL

CSA

RCM

EAC

Merchant Navy

Standards EN/IEC 61131-2

EN/IEC 61010-2-201

UL 61010-2-201

CSA C22.2 No 61010-2-201

IACS E10

EN/IEC 61000-6-5, interface type 1 and type 2

EN/IEC 61850-3, location G

Environmental characteristic Standard environment

IP degree of protection IP20

ambient air temperature for operation 0…60 °C

Ambient air temperature for storage -40…85 °C

Operating altitude <= 2000 m

Packing Units

Unit Type of Package 1 PCE

Number of Units in Package 1 1

Package 1 Height 5.5 cm

Package 1 Width 11.0 cm

Package 1 Length 11.8 cm

Package 1 Weight 262.0 g

Unit Type of Package 2 S02

Number of Units in Package 2 15

Package 2 Height 15.0 cm

Package 2 Width 30.0 cm

Package 2 Length 40.0 cm

Package 2 Weight 4.295 kg
